Car Wiring Diagrams for Ground distribution circuit for Mercury Mariner I (2004-2007)

A/C CLUTCH SOLENOID A/C COMPRESSOR CLUTCH DIODE ABS CONTROL MODULE ABS TEST CONNECTOR BATTERY BATTERY JUNCTION BOX (BJB) BLK WIRE DUAL PRESSURE SWITCH ANTI-THEFT HOOD SWITCH LEFT FRONT FOG LAMP LEFT FRONT PARK/TURN LAMP LEFT SIDE TURN SIGNAL LAMP MASS AIR FLOW (MAF SENSOR) NCA WIRE POWERTRAIN CONTROL MODULE (PCM) REVERSING LAMPS SWITCH RIGHT FRONT FOG LAMP RIGHT FRONT SIDE LAMP LEFT FRONT SIDE LAMP RIGHT SIDE TURN SIGNAL LAMP S131 (2.3L) (3.0L) S131 SHIELD SPEED CONTROL SERVO WINDSHIELD WIPER MOTOR WHT WIRE WINDSHIELD WASHER PUMP MOTOR

AIR BAG SLIDING CONTACT AUDIO UNIT AUTOLAMP SENSOR BASIC AUDIO PREMIUM AUDIO BLK WIRE BLK/WHT WIRE BLOWER MOTOR RELAY DATA LINK CONNECTOR (DLC) DRIVER SEAT POSITION SENSOR DRIVER SEAT BELT BUCKLE SENSOR EARLY PRODUCTION LATE PRODUCTION EXTERIOR REAR VIEW MIRROR SWITCH FLOOR SHIFTER FOG LAMP SWITCH FRONT BLOWER MOTOR RESISTOR ASSEMBLY FRONT CIGAR LIGHTER FUNCTION SELECTOR SWITCH ASSEMBLY HAZARD FLASHER SWITCH ILLUMINATION DIMMER INSTRUMENT CLUSTER LIGHT SWITCH LT BLU WIRE MESSAGE CENTER SWITCH OCCUPANT CLASSIFICATION SENSOR (OCS) MODULE PARKING AID DISABLE SWITCH PASSENGER SEAT BELT BUCKLE SENSOR PASSENGER SIDE SEAT BELT TENSIONER PASSIVE ANTI-THEFT TRANSCEIVER POWER POINT REAR WINDOW DEFROST SWITCH RESTRAINTS CONTROL MODULE SMART JUNCTION BOX (SJB) WHT WIRE WIPER/WASHER SWITCH

BATTERY JUNCTION BOX (BJB) BLK WIRE CARGO LAMP DRIVER SIDE FRONT DOOR LOCK UNIT DRIVER SIDE SEAT HEATER SWITCH ELECTRO- CHROMATIC INSIDE MIRROR UNIT ELECTRONIC COMPASS FRONT INTERIOR/ MAP LAMPS ASSEMBLY FUEL PUMP DRIVER MODULE FUEL PUMP RELAY PCM POWER RELAY INTELLIGENT TORQUE CONTROL COUPLING (ITCC) MODULE KEYPAD SWITCH ASSEMBLY LEFT LICENSE PLATE LAMP LEFT REAR DOOR LOCK ACTUATOR LEFT REAR PARK/STOP LAMP LEFT REAR TURN LAMP LEFT REVERSING LAMP PARKING AID MODULE (PAM) LEFT VANITY MIRROR LAMP ROOF OPENING PANEL UNIT LIFTGATE AJAR SWITCH LIFTGATE GLASS AJAR SWITCH LT GRN WIRE MASTER WINDOW/ DOOR LOCK/ UNLOCK SWITCH DRIVER SIDE EXTERIOR REAR VIEW MIRROR NCA WIRE PASSENGER SIDE DOOR LOCK SWITCH PASSENGER SIDE EXTERIOR REAR VIEW MIRROR PASSENGER SIDE FRONT DOOR LOCK UNIT PASSENGER SIDE FRONT HEATED SEAT MODULE PASSENGER SIDE SEAT HEATER SWITCH REAR WINDOW DEFROST GRID REAR WIPER MOTOR ASSEMBLY HIGH MOUNTED STOP LAMP RELAY RIGHT LICENSE PLATE LAMP RIGHT REAR DOOR LOCK ACTUATOR RIGHT REAR PARK/ STOP LAMP RIGHT REAR TURN LAMP RIGHT REVERSING LAMP RIGHT VANITY MIRROR LAMP RUN/ RUN/ ACCESSORY RELAY S132 (2.3L) (3.0L) S132 SHIELD SMART JUNCTION BOX (SJB) SUBWOOFER AMPLIFIER TRAILER TOW CONNECTOR WHT WIRE
