Computer data lines circuit for Mercury Mariner I (2004-2007)
Computer data lines circuit
15 14 12 13 MS CAN + MS CAN - HS CAN + HS CAN -
2 15 11 ISO HS CAN - HS CAN +
3 2 HS CAN + HS CAN -
4 12 HS CAN + HS CAN -
44 23 11 FEPS HS CAN - HS CAN +
ABS CONTROL MODULE
ABS TEST CONNECTOR
BLK WIRE
BLK/WHT WIRE
DATA LINK CONNECTOR (DLC)
FUSE 7
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTELLIGENT TORQUE CONTROL COUPLING (ITCC) MODULE
ISO
LT BLU/WHT WIRE
LT GRN WIRE
MS CAN +
ORG/ WIRE
ORG/LT GRN WIRE
PARKING AID MODULE (PAM)
PNK WIRE
PNK/ORG WIRE
POWERTRAIN CONTROL MODULE (PCM)
RESTRAINTS CONTROL MODULE
SMART JUNCTION BOX (SJB)
VIO WIRE
WHT WIRE
WHT/ORG WIRE
