Mercury Mariner I (2004-2007) rear park/ stop lamp Wiring diagram
This page shows the only wiring diagram for the component.rear park/ stop lamp, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear park/ stop lamp (1 of 1)
4) HEADLAMPS
AUTO LAMP SIG
BATTERY JUNCTION BOX (LEFT FRONT CORNER OF ENG COMPT)
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BPP SW INPUT
BRN WIRE
BRN/WHT WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 1
FUSE 3
FUSE 3 FUSE 2
FUSE 6
GROUND
HAZARD FLASHER SWITCH
HOT AT ALL TIMES
HZD FLASH SW SIG LEFT TURN SIG
INSTRUMENT CLUSTER
LEFT FRONT PARK/ TURN LAMP
LEFT TURN
LEFT TURN SIG
LEFT TURN SIG RIGHT TURN SIG
LIGHT SWITCH 1) AUTO 2) OFF 3) PARK
LO BEAM SIG
LOM 0.02 OHMS
LOW CURRENT BOARD RIGHT TURN
LR TRAILER TURN LAMP FEED RR TRAILER TURN LAMP FEED
LT BLU/BLK WIRE
LT BLU/RED WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
OFF
PARK
PARK LAMP RELAY
PARK LAMP SIG
REAR PARK/ STOP LAMP
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT PARK/ TURN LAMP
RIGHT LEFT
RIGHT TURN SIG
RIGHT TURN SIG LEFT TURN SIG
SIG
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TURN
VBATT
VBATT VBATT
WHT WIRE
WHT/BLK WIRE
WHT/LT BLU WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps & trailer connector circuit (1 of 2) -> REAR PARK/ STOP LAMP
