Mercury Mariner I (2004-2007) low fan ctrl cooling fan ctrl Wiring diagram
This page shows the only wiring diagram for the component.low fan ctrl cooling fan ctrl, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low fan ctrl cooling fan ctrl (1 of 1)
41 33 SIGRTNE CHT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/LT GRN WIRE
BLK/YEL WIRE
COOLING FAN RELAY
CYLINDER HEAD TEMPERATURE SENSOR
DK BLU WIRE
DUAL PRESSURE SWITCH
ENGINE CONTROLS SYSTEM
ENGINE COOLING FAN MOTOR 1
ENGINE COOLING FAN MOTOR 2
FUSE 22 FUSE 24
FUSE 5
GRY WIRE
GRY/RED WIRE
HI FAN CTRL ACPSW
HIGH SPEED FAN CONTROL RELAY 1
HOT AT ALL TIMES
HOT IN RUN OR START
LOW FAN CTRL COOLING FAN CTRL
LOW SPEED FAN CONTROL RELAY
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/VIO WIRE
ORG/ WIRE
PCM POWER DIODE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/ORG WIRE
SMART JUNCTION BOX (SJB)
VIO WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
YEL/LT GRN WIRE
Go to component -> 2.3l, cooling fan circuit -> LOW FAN CTRL COOLING FAN CTRL
