Mercury Mariner I (2004-2007) left outer parking aid sensor Wiring diagram
This page shows the only wiring diagram for the component.left outer parking aid sensor, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left outer parking aid sensor (1 of 1)
BLK WIRE
BLK/PNK WIRE
BRN/PNK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FUSE 29
GROUND
HOT IN RUN AND START
INNER LEFT SIGNAL
INNER RIGHT SIGNAL
ISO BUS
LEFT INNER PARKING AID SENSOR
LEFT OUTER PARKING AID SENSOR
LT BLU WIRE
LT BLU/WHT WIRE
OFF ON
ON/OFF SIG
ORG/ WIRE
OUTER LEFT SIGNAL
OUTER RIGHT SIGNAL
PARK AID ENABLE
PARK AID SPEAKER (-)
PARKING AID DISABLE SWITCH
PARKING AID MODULE (PAM)
PARKING AID SPEAKER
RED WIRE
RED/BLK WIRE
REF VOLTAGE
REVERSE LAMPS RELAY
RIGHT INNER PARKING AID SENSOR
RIGHT OUTER PARKING AID SENSOR
SIG RETURN
SMART JUNCTION BOX (SJB)
VIO WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
Go to component -> Parking assistant circuit -> LEFT OUTER PARKING AID SENSOR
