Mercury Mariner I (2004-2007) driver seat position sensor driver seat belt buckle sensor Wiring diagram
This page shows the only wiring diagram for the component.driver seat position sensor driver seat belt buckle sensor, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver seat position sensor driver seat belt buckle sensor (1 of 1)
AIR BAG SLIDING CONTACT
AUDIO UNIT
AUTOLAMP SENSOR
BASIC AUDIO PREMIUM AUDIO
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR RELAY
DATA LINK CONNECTOR (DLC)
DRIVER SEAT POSITION SENSOR DRIVER SEAT BELT BUCKLE SENSOR
EARLY PRODUCTION LATE PRODUCTION
EXTERIOR REAR VIEW MIRROR SWITCH
FLOOR SHIFTER
FOG LAMP SWITCH
FRONT BLOWER MOTOR RESISTOR ASSEMBLY
FRONT CIGAR LIGHTER
FUNCTION SELECTOR SWITCH ASSEMBLY
HAZARD FLASHER SWITCH
ILLUMINATION DIMMER
INSTRUMENT CLUSTER
LIGHT SWITCH
LT BLU WIRE
MESSAGE CENTER SWITCH
OCCUPANT CLASSIFICATION SENSOR (OCS) MODULE
PARKING AID DISABLE SWITCH
PASSENGER SEAT BELT BUCKLE SENSOR
PASSENGER SIDE SEAT BELT TENSIONER
PASSIVE ANTI-THEFT TRANSCEIVER
POWER POINT
REAR WINDOW DEFROST SWITCH
RESTRAINTS CONTROL MODULE
SMART JUNCTION BOX (SJB)
WHT WIRE
WIPER/WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 3) -> DRIVER SEAT POSITION SENSOR DRIVER SEAT BELT BUCKLE SENSOR
