Mercury Mariner I (2004-2007) door on Wiring diagrams
This page contains all the electrical diagrams for the component. door on, in which he is found in the car Mercury Mariner I (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram door on (1 of 2)
AJAR
BATTERY JUNCTION BOX (BJB)
BATTERY SAVER
BLK WIRE
BLK/WHT WIRE
CARGO LAMP
DK BLU WIRE
DOOR ON
DRIVER SIDE FRONT DOOR LOCK UNIT
FRONT INTERIOR LAMP
FUSE 2
FUSE 3
HOT AT ALL TIMES
INTERIOR DOME LAMPS
LEFT REAR DOOR LOCK ACTUATOR
LEFT VANITY MIRROR LAMP
LF DOOR AJAR
LR DOOR AJAR
LT GRN/BLK WIRE
LT GRN/YEL WIRE
OFF
OFF ON OFF
ON OFF
PASSENGER SIDE FRONT DOOR LOCK UNIT
PNK WIRE
PNK/LT BLU WIRE
RF DOOR AJAR
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR
SJB LOGIC
SMART JUNCTION BOX (SJB)
VBATT
VIO/LT GRN WIRE
VIO/ORG WIRE
WHT WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit, without roof opening panel -> DOOR ON
