Mercury Mariner I (2004-2007) clutch switch wiring diagram
This page shows the only wiring diagram for the component.clutch switch, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
clutch switch wiring diagram (1 of 1)
A/T
ABS CONTROL MODULE
AIR BAG SLIDING CONTACT
AUDIO UNIT
BLK WIRE
BRAKE PEDAL POSITION SWITCH
CLUTCH SWITCH
CRUISE CONTROL
DEACT- IVATOR SWITCH
DK GRN WIRE
DK GRN/ORG WIRE
EARLY PRODUCTION
EARLY PRODUCTION LATE PRODUCTION
FUSE 27
FUSE 34
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
LATE PRODUCTION
LATE PRODUCTION EARLY PRODUCTION
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/PNK WIRE
LT BLU/YEL WIRE
LT GRN WIRE
M/T
NCA WIRE
OFF
ORG/ WIRE
ORG/LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/LT GRN WIRE
RESUME COAST
SET/ ACCEL
SMART JUNCTION BOX (SJB) FUSE 6
SPEED CONTROL SERVO
STEERING WHEEL/SPEED CONTROL SWITCH
W/ PREMIUM SOUND SYSTEM
YEL WIRE
Go to component -> Cruise control circuit -> CLUTCH SWITCH
