Mercury Mariner I (2004-2007) bpp sw in right rear - right rear + Wiring diagram
This page shows the only wiring diagram for the component.bpp sw in right rear - right rear +, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bpp sw in right rear - right rear + (1 of 1)
ABS CONTROL MODULE
ABS TEST CONNECTOR
AUDIO UNIT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/WHT WIRE
BPP SW IN RIGHT REAR - RIGHT REAR +
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION SWITCH
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR
FUSE 15
FUSE 20
FUSE 34
FUSE 6
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
HS CAN - SIG GND
HS CAN+
LEFT FRONT + LEFT FRONT - GND
LEFT FRONT WHEEL SPEED SENSOR
LEFT REAR + LEFT REAR -
LEFT REAR WHEEL SPEED SENSOR
LT BLU WIRE
LT BLU/PNK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NCA WIRE
PNK/BLK WIRE
RED WIRE
RED/PNK WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT REAR WHEEL SPEED SENSOR
SMART JUNCTION BOX (SJB)
SPEED CONTROL SERVO
STS BFLSRET
TAN/BLK WIRE
TAN/LT GRN WIRE
TAN/ORG WIRE
VBATT RIGHT FRONT - RIGHT FRONT +
VIO/YEL WIRE
VPWR
VSS
WHT WIRE
YEL/BLK WIRE
YEL/LT GRN WIRE
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit -> BPP SW IN RIGHT REAR - RIGHT REAR +
