Mercury Mariner I (2004-2007) audio unit air bag sliding contact wiring diagram
This page shows the only wiring diagram for the component.audio unit air bag sliding contact, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
audio unit air bag sliding contact wiring diagram (1 of 1)
2.3L 3.0L
ALL DOOR LOCK RELAY
AUDIO UNIT AIR BAG SLIDING CONTACT
BATTERY JUNCTION BOX (BJB)
BLK WIRE
COOLING FAN RELAY
DATA LINK CONNECTOR (DLC)
DK BLU WIRE
DRIVER UNLOCK RELAY
FROM FUSE 5 (SJB) (DIAGRAM 3 OF 4)
FROM FUSE 7 (BJB) (DIAGRAM 1 OF 4)
FUEL PUMP RELAY HIGH SPEED FAN CONTROL RELAY 1 HIGH SPEED FAN CONTROL RELAY 2
FUSE 1 FUSE 3
FUSE 17
FUSE 2
FUSE 20
FUSE 21
FUSE 7
FUSE 9 FUSE 6
HORN RELAY
INSTRUMENT CLUSTER
LOGIC
LOW SPEED FAN CONTROL RELAY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER
PCM POWER RELAY
PREMIUM AUDIO BASIC AUDIO
RED WIRE
RIGHT HORN LEFT HORN
SJB LOGIC BOARD
SMART JUNCTION BOX (SJB)
STARTER RELAY
TO FUSE 4 (SJB) (DIAGRAM 3 OF 4)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> AUDIO UNIT AIR BAG SLIDING CONTACT
