Mercury Mariner I (2004-2007) 2 31 42 strt out tx rx Wiring diagram
This page shows the only wiring diagram for the component.2 31 42 strt out tx rx, which is found in the car Mercury Mariner I (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 31 42 strt out tx rx (1 of 1)
1 2 3 4 VPWR GND TX RX
2 31 42 STRT OUT TX RX
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/WHT WIRE
BRN/ORG WIRE
DK BLU WIRE
DK BLU/ORG WIRE
HOT IN START OR RUN
LT BLU WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER
PCM POWER DIODE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RED/BLK WIRE
SMART JUNCTION BOX (SJB) FUSE 5
STARTER RELAY
STARTER RELAY DIODE
VIO WIRE
WHT WIRE
WHT/VIO WIRE
Go to component -> Passive anti-theft circuit -> 2 31 42 STRT OUT TX RX
