Car Wiring Diagrams for Charging circuit for Mercury Cougar VIII (1998-2002)

2.0L 2.5L BATTERY BATTERY JUNCTION BOX (LEFT FRONT CORNER OF ENG COMPT) BLK WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CHARGE INDICATOR FUSE 2 FUSE 30 GENERATOR GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER MEGA FUSE ORG/YEL WIRE PCM (RIGHT REAR OF ENGINE COMPT) (2.0L ONLY) RED WIRE STARTER MOTOR WHT WIRE WHT/GRN WIRE
