Cooling fan circuit for Mercury Cougar VIII (1998-2002)
Cooling fan circuit
BATTERY JUNCTION BOX (LEFT FRONT CORNER OF ENGINE COMPARTMENT)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
ENGINE COOLING FAN MOTOR (LEFT FRONT OF ENGINE COMPARTMENT)
ENGINE COOLING FAN RELAY
ENGINE COOLING FAN RESISTOR (BELOW ENGINE COOLING FAN MOTOR)
FUSE 49
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
HIGH SPEED ENGINE COOLING FAN RELAY
HOT AT ALL TIMES
ORG/ WIRE
PCM POWER RELAY
RED WIRE
SECOND COOLING FAN MOTOR (RIGHT FRONT OF ENGINE COMPARTMENT)
SOLID STATE
W/AIR CONDITIONING
W/O AIR CONDITIONING
WHT WIRE
WHT/GRN WIRE
YEL WIRE
