Mercury Cougar VIII (1998-2002) up/ close down/ open Wiring diagram
This page shows the only wiring diagram for the component.up/ close down/ open, which is found in the car Mercury Cougar VIII (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up/ close down/ open (1 of 1)
BLK WIRE
CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DOWN, OPEN UP, CLOSE
FUSE 21
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HOT IN RUN OR START
SLIDING ROOF ADJUST SWITCH
SLIDING ROOF END POSITION MICROSWITCH
SLIDING ROOF MOTOR
SLIDING ROOF OPENING PANEL UNIT (CENTER OF HEADLINER)
SLIDING ROOF RELAY
SLIDING ROOF SWITCH CLOSE/OPEN
SLIDING ROOF SWITCH UP/DOWN
UP/ CLOSE DOWN/ OPEN
Go to component -> Power top/sunroof circuits -> UP/ CLOSE DOWN/ OPEN
