Mercury Cougar VIII (1998-2002) pats indicator Wiring diagrams

This page contains all the electrical diagrams for the component. pats indicator, in which he is found in the car Mercury Cougar VIII (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram pats indicator (1 of 3)

Wiring diagram pats indicator for Mercury Cougar VIII (1998-2002) (1 of 3)

Get lifetime access to Mercury Cougar VIII (1998-2002)

2.0L 2.5L ANTI-THEFT/ CENTRAL LOCKING MODULE (ON CENTER OF RIGHT "A" PILLAR) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/YEL WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) CENTRAL TIMER DRIVER DOOR LOCK/ UNLOCK SWITCH FUSE 25 FUSE 30 FUSE 34 GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START LOCK MODULE ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE ORG/YEL WIRE PASSENGER DOOR LOCK/UNLOCK SWITCH PATS INDICATOR RADIO TAILGATE/ DECKLID ANTI-THEFT INHIBIT SWITCH (RIGHT REAR OF VEHICLE) TRUNK/TAILGATE FUEL DOOR RELEASE SYSTEM UNLK VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component -> Forced entry circuit (1 of 2) -> PATS INDICATOR

Wiring diagram pats indicator (2 of 3)

Wiring diagram pats indicator for Mercury Cougar VIII (1998-2002) (2 of 3)

Get lifetime access to Mercury Cougar VIII (1998-2002)

BATTERY JUNCTION BOX (UNDER LEFT SIDE OF DASH) BLK WIRE BLU WIRE CENTRAL JUNCTION BOX (UNDER LEFT SIDE OF DASH) DAYTIME RUNNING LAMPS (DRL) RELAY PCM POWER RELAY DURETEC-VE FROM FUSE 36 (DIAGRAM 1 OF 4) FROM IGNITION RELAY DIAGRAM (2 OF 4) FRONT INTERIOR LAMP FUSE 11 FUSE 34 GRN WIRE GRN/BLU WIRE HIGH OPTION HIGHER OPTION IGNITION TRANSFORMER IGNITION TRANSFORMER CAPACITOR IGNITION TRANSFORMER IGNITION TRANSFORMER CAPACITOR INSTRUMENT CLUSTER LEFT VANITY MIRROR LAMP RIGHT VANITY MIRROR LAMP LOW OPTION LOWER OPTION NCA WIRE ORG/ WIRE PATS INDICATOR PCM POWER RELAY POWER MIRROR ADJUST SWITCH LUGGAGE COMPARTMENT LAMP RED WIRE VTEC-VCT W/DAYTIME RUNNING LAMPS W/O DAYTIME RUNNING LAMPS WHT WIRE YEL WIRE

Go to component -> Power distribution circuit (3 of 4) -> PATS INDICATOR
