Mercury Cougar VIII (1998-2002) over- drive cancel switch Wiring diagram
This page shows the only wiring diagram for the component.over- drive cancel switch, which is found in the car Mercury Cougar VIII (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram over- drive cancel switch (1 of 1)
AIR TEMPERATURE ACTUATOR
ANTI-THEFT/ CENTRAL LOCKING MODULE
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
CENTRAL JUNCTION BOX (CJB) (UNDER LEFT SIDE OF DASH) FUSE 23
CRUISE CONTROL SYSTEM
FUSE 24
FUSE 25
FUSE 30
GEAR- SHIFT LEVER UNIT
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEATER MODE SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
ILLUM. LAMP PARK LOCK SOL
INSTRUMENT INTERFACE MODULE (BEHIND LEFT SIDE OF DASH)
KEY REMOVAL INHIBIT SOLENOID (ON STEERING COLUMN)
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/WHT WIRE
ORG/YEL WIRE
OVER- DRIVE CANCEL SWITCH
POWER DISTRIBUTION CIRCUIT
POWERTRAIN CONTROL MODULE (BEHIND POWER STEERING RESERVOIR)
RED WIRE
STOPLAMP SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
W/LOWER OPTION CONTENT
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> OVER- DRIVE CANCEL SWITCH
