Mercury Cougar VIII (1998-2002) front seat forward/ reverse motor Wiring diagram

This page shows the only wiring diagram for the component.front seat forward/ reverse motor, which is found in the car Mercury Cougar VIII (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front seat forward/ reverse motor (1 of 1)

Wiring diagram front seat forward/ reverse motor for Mercury Cougar VIII (1998-2002) (1 of 1)

Get lifetime access to Mercury Cougar VIII (1998-2002)

BLK WIRE BLU WIRE CENTRAL JUNCTION BOX DEFLATE DN UP FRONT SEAT FORWARD/ REVERSE MOTOR FRONT SEAT HEIGHT MOTOR FWD REV GRN WIRE HOT AT ALL TIMES FUSE 28 INFLATE LUMBAR COM- PRESSOR MOTOR ORG/YEL WIRE POWER SEAT SWITCH RECLINER MOTOR RED WIRE REV FWD WHT WIRE YEL WIRE

Go to component -> 8-way adjustable power seat circuit -> FRONT SEAT FORWARD/ REVERSE MOTOR
