Mercury Cougar VIII (1998-2002) driver side for passenger side window operating switch Wiring diagram
This page shows the only wiring diagram for the component.driver side for passenger side window operating switch, which is found in the car Mercury Cougar VIII (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side for passenger side window operating switch (1 of 1)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX
DRIVER POWER WINDOW SWITCH
DRIVER SIDE FOR PASSENGER SIDE WINDOW OPERATING SWITCH
FRONT DRIVER SIDE WINDOW REGULATING MOTOR
FRONT PASSENGER SIDE WINDOW REGULATING MOTOR
FUSE 21
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
HOT IN RUN OR START
ONE- TOUCH WINDOW RELAY (FRONT OF LEFT FRONT DOOR)
ORG/ WIRE
PASSENGER SIDE WINDOW OPERATING SWITCH
SOLID STATE
UP DN
UP UP DN
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> DRIVER SIDE FOR PASSENGER SIDE WINDOW OPERATING SWITCH
