Car Wiring Diagrams for 4.6l, charging circuit for Mercury Cougar VII (1989-1997)

A SCREW F SCREW B+ RECTIFIER BATTERY BLK WIRE CHARGING WARNING INDICATOR GENERATOR, VOLTAGE REGULATOR HOT AT ALL TIMES IGNITION SWITCH IN-LINE FUSE INSTRUMENT CLUSTER LOCK OFF LT GRN/RED WIRE ORG/ WIRE POWER DISTRIBUTION BOX RED WIRE RED/LT GRN WIRE REGULATOR RUN WIRE SENSING, SWITCHING CIRCUITS FIELD STARTER MOTOR SOLENOID STATOR STD FUSE 11 WHT WIRE YEL WIRE
