Car Wiring Diagrams for Cooling fan circuit for Mercury Cougar VII (1989-1997)

14 17 (3.8L) (4.6L) (3.8L) (4.6L) 13 68 1995 VFTC 4.6L ONLY BLK WIRE BLK/ORG WIRE BRN WIRE BRN/ORG WIRE DK BLU WIRE EDF RELAY EDF RELAY CONTROL HEDF RELAY ELECTRIC COOLING FAN ENGINE CONTROLS SYSTEM FL 15 FL 3 FL 5 HOT AT ALL TIMES HOT IN START OR RUN IN-LINE FUSE LT GRN/PPL WIRE ORG/ WIRE PCM POWER RELAY POWER DISTRIBUTION BOX POWER- TRAIN CONTROL MODULE (BEHIND RIGHT COWL) RED WIRE RED/LT GRN WIRE RED/ORG WIRE SOLID STATE SUPPORT) TAN/ORG WIRE YEL WIRE
