Mercury Cougar VII (1989-1997) integrated control module warning chime module Wiring diagram
This page shows the only wiring diagram for the component.integrated control module warning chime module, which is found in the car Mercury Cougar VII (1989-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram integrated control module warning chime module (1 of 1)
BAT IGN
BLK WIRE
BRN WIRE
CLUSTER FUSE
DK GRN WIRE
DOOR COURTESY LAMP SWITCH INPUT
FASTEN BELTS INDICATOR
FUSE
GROUND
HOT AT ALL TIMES
HOT IN ACCY OR RUN
HOT IN RUN OR START
INSTRUMENT CLUSTER
INT LPS FUSE
INTEGRATED CONTROL MODULE (PRIMARY JUNCTION BLOCK)
INTEGRATED CONTROL MODULE WARNING CHIME MODULE
KEY WARNING SWITCH
LAMPS SEAT BELT INPUT LAMP OUTPUT
LEFT DOOR COURTESY LAMP SWITCH
LEFT DOOR LATCH SWITCH (BEHIND LEFT COWL PANEL, NEAR FRONT OF DOOR SILL)
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
NCA WIRE
OFF HEAD PARK
PNK WIRE
PRIMARY JUNCTION BLOCK
PRIMARY JUNCTION BLOCK (LEFT SIDE OF I/P)
RED WIRE
RED/PNK WIRE
RIGHT DOOR LATCH SWITCH
RUN/ACCY POWER KEY IN IGNITION INPUT
SEAT BELT BUCKLED INPUT
SEAT BELT SWITCH
START/RUN POWER DOOR INPUT
WARNING CHIME MODULE
WHT WIRE
YEL WIRE
Go to component -> Warning system circuits -> INTEGRATED CONTROL MODULE WARNING CHIME MODULE
