Front heated seats circuit, w/ memory for Mercedes-Benz Vito W447 facelift (2018-2024)
Front heated seats circuit, w/ memory
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT ADJUSTMENT W/ MEMORY CONTROL UNIT
DRIVER SEAT BACKREST HEATER PAD
DRIVER SEAT CUSHION HEATER PAD
FIREWALL FUSE, RELAY MODULE
FRONT PASSENGER SEAT ADJUSTMENT W/ MEMORY CONTROL UNIT
FRONT PASSENGER SEAT BACKREST HEATER PAD
FRONT PASSENGER SEAT CUSHION HEATER PAD
FUSE 59
FUSE 60
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LEFT SEAT CLIMATE CONTROL SWITCH GROUP
LEFT SEAT HEATER BUTTON
LIN B
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT SEAT CLIMATE CONTROL SWITCH GROUP
RIGHT SEAT HEATER BUTTON
WHT/BLU WIRE
WHT/BRN WIRE
WHT/PNK WIRE
