Mercedes-Benz Vito W447 facelift (2018-2024) Data link connector circuit

Data link connector circuit

Car Wiring Diagrams for Vito Mercedes-Benz W447 facelift (2018-2024): Data link connector circuit

BRN WIRE CAN-D H CAN-D L DIAGNOSTIC CONNECTOR ELECTRONIC IGNITION LOCK (EZS) CONTROL UNIT FIREWALL FUSE, RELAY MODULE FUSE 87 GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES RED/ORG WIRE
