Mercedes-Benz Vito W447 facelift (2018-2024) rain light sensor w/ additional functions Wiring diagram

BLK/GRN WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/PNK WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B H CAN B L CENTER TRUNK LAMP COC COMPUTER DATA LINES SYSTEM DREHF - DREHF SIG GND LDS GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE INSTRUMENT ILLUMINATION BRIGHTNESS CONTROL LEFT EXIT, WARNING LAMP LEFT FRONT FOOTWELL LAMP LEFT FRONT GRAB HANDLE AMBIANCE ILLUMINATION LEFT REAR GRAB HANDLE AMBIANCE ILLUMINATION LIGHT SENSOR (-) LIGHT SWITCH RAIN LIGHT SENSOR W/ ADDITIONAL FUNCTIONS REAR OF REAR DOME LAMP RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) RIGHT FRONT FOOTWELL LAMP RIGHT FRONT GRAB HANDLE AMBIANCE ILLUMINATION RIGHT REAR GRAB HANDLE AMBIANCE ILLUMINATION SIG LDS 1 SIG LDS 2 SIG LDS 3 SIG LWR SIGNAL ACQUISITION, ACTUATION MODULE (SAM) CONTROL UNIT VIO/GRN WIRE W/ LIFTGATE AMBIENT ILLUMINATION W/ READING SPOTLIGHT W/ SMOKER'S PACKAGE WHT WIRE YEL WIRE ZV HKL - ZV HKL AT
