Mercedes-Benz Vito W447 facelift (2018-2024) humidity sensor/ light sensor/rain sensor Wiring diagram
This page shows the only wiring diagram for the component.humidity sensor/ light sensor/rain sensor, which is found in the car Mercedes-Benz Vito W447 facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram humidity sensor/ light sensor/rain sensor (1 of 1)
AUTOMATICALLY DIMMING INSIDE REAR VIEW MIRROR/ MIRROR TAXIMETER
BLK/GRY WIRE
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
EC SIG
EC+
FIREWALL FUSE, RELAY MODULE
FUSE 101
FUSE 64
FUSE 65
GRY WIRE
HOT AT ALL TIMES
HUMIDITY SENSOR/ LIGHT SENSOR/RAIN SENSOR
HUMIDITY SENSOR/ LIGHT SENSOR/RAIN SENSOR/ SUN SENSOR
HUMIDITY, LIGHT SENSOR
LEFT FRONT DOOR CONTROL UNIT
LEFT MIRROR DIMMING
LEFT OUTSIDE MIRROR
OVERHEAD CONTROL PANEL (OCP (DBE)) CONTROL UNIT
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT MIRROR DIMMING
RIGHT OUTSIDE MIRROR
W/ RAIN SENSOR
WHT WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> HUMIDITY SENSOR/ LIGHT SENSOR/RAIN SENSOR
