Mercedes-Benz Vito W447 facelift (2018-2024) external operation reversing camera/ 360 degree camera liftgate open switch Wiring diagram
This page shows the only wiring diagram for the component.external operation reversing camera/ 360 degree camera liftgate open switch, which is found in the car Mercedes-Benz Vito W447 facelift (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram external operation reversing camera/ 360 degree camera liftgate open switch (1 of 1)
BLK/GRN WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/PNK WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
CAN B H
CAN B L
CARGO VAN
COMPUTER DATA LINES SYSTEM
DREHF -
DREHF SIG
EXTERNAL OPERATION LIFTGATE OPEN SWITCH
EXTERNAL OPERATION REVERSING CAMERA/ 360 DEGREE CAMERA LIFTGATE OPEN SWITCH
GRN/BRN WIRE
GRY/BLU WIRE
LEFT FRONT DOOR CENTRAL LOCKING ACTUATOR
LEFT FRONT GRAB HANDLE DOME LAMP
LEFT FRONT VANITY MIRROR ILLUMINATION
LEFT REAR GRAB HANDLE DOME LAMP
LEFT SUN VISOR ILLUMINATION SWITCH
NCA WIRE
PASSENGER VAN
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT EXIT, WARNING LAMP
RIGHT FRONT DOOR CENTRAL LOCKING ACTUATOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT GRAB HANDLE DOME LAMP
RIGHT FRONT VANITY MIRROR ILLUMINATION
RIGHT REAR GRAB HANDLE DOME LAMP
RIGHT SUN VISOR ILLUMINATION SWITCH
ROTARY TUMBLER MICRO SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO/GRN WIRE
W/ BACKUP CAMERA
W/O BACKUP CAMERA
Go to component -> Interior lights circuit (3 of 3) -> EXTERNAL OPERATION REVERSING CAMERA/ 360 DEGREE CAMERA LIFTGATE OPEN SWITCH
