Tire pressure monitoring circuit for Mercedes-Benz SLK-class AMG R172 (2011-2016)

BRN WIRE CAN E H CAN E L COMPUTER DATA LINES SYSTEM FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE FUSE 28 FUSE 70 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED INSTRUMENT CLUSTER LEFT FRONT TIRE PRESSURE (RDK) SENSOR LEFT REAR TIRE PRESSURE (RDK) SENSOR REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE RED WIRE RED/VIO WIRE RIGHT FRONT TIRE PRESSURE (RDK) SENSOR RIGHT REAR INTERIOR RIGHT REAR TIRE PRESSURE (RDK) SENSOR TIRE PRESSURE MONITOR CONTROL UNIT TIRE PRESSURE MONITOR WARNING LAMP VIO WIRE YEL WIRE YEL/RED WIRE
