Mercedes-Benz SLK-class AMG R172 (2011-2016) vertical dynamics button Wiring diagram
This page shows the only wiring diagram for the component.vertical dynamics button, which is found in the car Mercedes-Benz SLK-class AMG R172 (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vertical dynamics button (1 of 1)
ADAPTIVE DAMPING SYSTEM CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/ORG WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
EARLY PRODUCTION
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 18
FUSE 40
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
H SIDE
HOT AT ALL TIMES
HOT W/ SEAT ADJUSTMENT RELAY ENERGIZED
L SIDE
LATE PRODUCTION
LEFT AIR SCARF BUTTON
LEFT FRONT LEVEL SENSOR
LEFT REAR AXLE DAMPING VALVE UNIT
LEFT REAR LEVEL SENSOR
LIN
NCA WIRE
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
RED/BLK WIRE
RED/BLU WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT AIR SCARF BUTTON
RIGHT REAR AXLE DAMPING VALVE UNIT
RIGHT REAR BODY LATERAL ACCELERATION SENSOR
RIGHT REAR LEVEL SENSOR
SIG
UPPER CONTROL PANEL CONTROL UNIT
VERTICAL DYNAMICS BUTTON
VIO WIRE
Go to component -> Electronic suspension circuit (1 of 2) -> VERTICAL DYNAMICS BUTTON
