Mercedes-Benz SLK-class AMG R172 (2011-2016) electronic stability program control module Wiring diagram
This page shows the only wiring diagram for the component.electronic stability program control module, which is found in the car Mercedes-Benz SLK-class AMG R172 (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic stability program control module (1 of 1)
ACTIVE CURVE ILLUMINATION ACTUATOR MOTOR
BLK WIRE
BLK/GRN WIRE
BLS H
BLS L
BLS M
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
ELECTRONIC STABILITY PROGRAM CONTROL MODULE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/RED WIRE
HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR
ORG/ WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT LAMP UNIT
SIDE MARKER LAMP
STANDING/ PARKING LAMP
STOPLIGHT SWITCH
TURN SIGNAL LAMP
W/ XENON HEADLAMPS
W/O XENON HEADLAMPS
WHT WIRE
WHT/BLK WIRE
XENON LAMP CONTROL UNIT
XENON LIGHT POWER SUPPLY MODULE
YEL WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> ELECTRONIC STABILITY PROGRAM CONTROL MODULE
