Mercedes-Benz S-class W221 facelift (2009-2013) left seat selection can-al can-ah button Wiring diagram

"FORWARD" BUTTON 1 2 3 31 LIN-BUS 30 13 3 CAN-A L CAN-A H 31 PROGKEY CAN-A L WBS-OUT 30 CAN-A H WBS-IN WBS-LED 5 13 16 6 7 LSP+ LSP- ANTENNA SPLITTER BACK BUTTON BACKREST SIDE SEAT CONTOUR BUTTON BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE BUTTON "BACK" BUTTON "ON" CAN B H CAN B L CAN D H CAN D L CENTER CONSOLE BUTTON GROUP COMAND CONTROL UNIT COMPUTER DATA LINES SYSTEM DISC/RADIO QUICK SELECT BUTTON EMERGENCY CALL SYSTEM CONTROL UNIT (LEFT FRONT OF TRUNK) FIRM MASSAGE FUNCTION BUTTON FREELY PROGRAMM- ABLE BUTTON FRONT CENTRAL OPERATING UNIT GENTLE MASSAGE FUNCTION BUTTON GPS GRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HAZARD WARNING SYSTEM BUTTON HEAD RESTRAINT FOLDING BUTTON INCREASE VOLUME BUTTON LEFT "BACK" BUTTON LEFT REAR FOOTWELL LEFT SCREEN BUTTON LEFT SEAT SELECTION CAN-AL CAN-AH BUTTON LUMBAR SUPPORT HEIGHT ADJUSTMENT BUTTON LUMBAR SUPPORT SEAT CONTOUR BUTTON MULTI- CONTOUR SEAT QUICK SELECT BUTTON NCA WIRE PORTABLE CTEL ANTENNA AMPLIFIER (LEFT SIDE OF TRUNK) RCP(HBF) CONTROL UNIT REAR TURN/ FUSH CONTROL REAR WINDOW ROLLER SUN BLIND BUTTON RED WIRE RED/WHT WIRE REDUCE VOLUME BUTTON RIGHT "BACK" BUTTON RIGHT SCREEN BUTTON RIGHT SEAT SELECTION BUTTON TELEPHONE, GPS ROOF ANTENNA TELEPHONE/ NAVIGATION QUICK SELECT BUTTON TRANSMISSION MODES BUTTON TURN/ PUSH CONTROL UHI PORTABLE CTEL HOLDER (UNIVERSAL HANDY INTERFACE) UNIVERSAL PORTABLE CTEL INTERFACE (UPCI (UHI)) CONTROL MODULE UPPER CONTROL PANEL CONTROL MODULE VIO WIRE VOLUME CONTROL WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
