Power top/sunroof circuit for Mercedes-Benz S-class W220 facelift (2002-2005)

1 2 3 4 30 31 CAN-B H CAN B-L 1 2 3 4 5 6 10 9 SR (+) SR (-) 31 UKB UKB BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT SR OBSTRUCTION SENSOR FUSE 77 GRN WIRE HOT AT ALL TIMES OVERHEAD CONTROL PANEL CONTROL MODULE (ABOVE CENTER REAR VIEW MIRROR) REAR FUSE/RELAY MODULE (UNDER RIGHT REAR SEAT) RED WIRE RED/BLK WIRE SLIDING/POP-UP ROOF DRIVE ASSEMBLY (FRONT CENTER OF SLIDING DOOR) SR (SHD) OBSTRUCTION SENSOR UNIT (LEFT FRONT SIDE OF SLIDING DOOR) SR SWITCH VIO WIRE WHT WIRE YEL WIRE
