Trunk, tailgate, fuel door circuit for Mercedes-Benz S-class W220 (1998-2005)

1 4 2 HD HD-SVS 3 4 1 CAN-B L CAN-B H 9 10 1 CAN-B H CAN-B L BLU/GRN WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE POWER WINDOW SWITCH GROUP GRY/BLU WIRE GRY/PNK WIRE LEFT FRONT DOOR CONTROL MODULE (IN LEFT FRONT DOOR) PSE CONTROL MODULE (ON LEFT SIDE OF TRUNK) REMOTE TRUNK LID OPENING VALVE (CENTER OF TRUNK LID, PART OF TRUNK LID LOCK) REMOTE TRUNK RELEASE SWITCH (CENTER OF TRUNK LID) TRUNK RELEASE SWITCH
