Back-up lamps circuit, sedan for Mercedes-Benz S-class W140 facelift (1994-1999)
Back-up lamps circuit, sedan
AUTO DIMMING INSIDE REAR-VIEW MIRROR
BACKUP
BRN WIRE
ENGINE CONTROL MODULE
EXTERIOR LAMP FAILURE MONITORING MODULE (IN LEFT REAR OF ENGINE COMPT)
GRY WIRE
GRY/YEL WIRE
GRY/YEL/WHT WIRE
LEFT TAILLAMP UNIT
PSE CONTROL MODULE
RIGHT TAILLAMP UNIT
TRANSMISSION RANGE RECOGNITION SWITCH (ON GEAR SHIFT SELECTOR ASSEMBLY)
YEL WIRE
YEL/WHT WIRE
