Mercedes-Benz S-class W140 facelift (1994-1999) dn to limit up to limit up dn up to limit Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/GRY WIRE CENTER CONSOLE CENTER CONSOLE REAR POWER WINDOWS CONVENIENCE CONTROL UNIT DATA LINK CONNECTOR DN TO LIMIT DN TO LIMIT UP DN UP TO LIMIT DN TO LIMIT UP TO LIMIT UP DN UP TO LIMIT FRONT CENTER CONSOLE LEFT FRONT POWER WINDOW SWITCH FRONT CENTER CONSOLE LEFT REAR POWER WINDOW SWITCH FRONT CENTER CONSOLE RIGHT REAR POWER WINDOW SWITCH FUSE 11 FUSE 5 FUSE 6 FUSE BOX FUSE 35 GRN WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ACC, RUN, START LEFT FRONT DOOR SWITCH LEFT FRONT POWER WINDOW MOTOR LEFT REAR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH PNK/BLK WIRE PNK/BLU WIRE PNK/GRN WIRE PNK/GRY WIRE PNK/VIO WIRE PNK/WHT WIRE PNK/YEL WIRE REAR FUSE BOX RED/GRN WIRE RED/WHT WIRE RED/WHT/YEL WIRE RED/YEL WIRE RIGHT FRONT DOOR SWITCH RIGHT FRONT POWER WINDOW MOTOR RIGHT FRONT POWER WINDOW SWITCH RIGHT REAR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH SAFETY SWITCH UP DN UP DN TO LIMIT UP TO LIMIT WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/VIO WIRE YEL/WHT WIRE
