Mercedes-Benz S-class W140 (1991-1998) see system diagram for pin number Wiring diagram

1995-96 2 3 W/ ELECTRONIC ACCELERATOR W/O ELECTRONIC ACCELERATOR A/C PUSHBUTTON CONTROL MODULE ADS CONTROL MODULE (IN MODULE BOX, ON RIGHT REAR OF ENGINE COMPT) ATA CONTROL MODULE (ON RIGHT SIDE OF LUGGAGE COMPT) BASE MODULE (IN MODULE BOX, ON RIGHT REAR OF ENGINE COMPT) BLK/BLU WIRE BLK/YEL WIRE BLU/GRY WIRE BRN WIRE CAN 3 8 1 CAN H+ CAN 3 19 CAN L CAN L- 3 18 CAN-H CONVENIENCE FEATURE CONTROL MODULE (ON RIGHT SIDE OF LUGGAGE COMPT) DIAGNOGSTIC MODULE (OBD II) ENGINE CONTROL MODULE (HFM-SFI) FUSE 15 FUSE 17 FUSE BOX GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/PPL WIRE GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START INFRARED REMOTE CONTROL MODULE (ON RIGHT SIDE OF LUGGAGE COMPT) INSTRUMENT CLUSTER NCA WIRE PNK WIRE PSE CONTROL MODULE (RIGHT SIDE OF REAR SEAT) RED WIRE RED/WHT WIRE SEE SYSTEM DIAGRAM FOR PIN NUMBER SPS CONTROL MODULE SRS CONTROL MODULE SRS IND TEST CONNECTOR FOR DIAGNOSIS (RIGHT REAR CORNER OF ENGINE COMPARTMENT) TRANSMISSION CONTROL MODULE W/ ASR W/O ASR WHT WIRE WHT/GRN WIRE YEL WIRE YEL/RED (OR YEL/BLU) WIRE YEL/RED WIRE
