Power top/sunroof circuits for Mercedes-Benz S-class AMG W220 (1999-2002)

1 2 3 4 30 31 CAN-B H CAN B-L 1 2 3 4 5 6 11 10 9 SHD (+) SHD (-) 31 UKB UKB UKB BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT SR JAMMING PROTECTOR FUSE 77 GRN WIRE HOT AT ALL TIMES REAR FUSE BOX (IN LUGGAGE COMPT, BEHIND RIGHT TRIM PANEL) REAR SR JAMMING PROTECTOR RED WIRE RED/BLK WIRE ROOF CONTROL UNIT CONTROL MODULE (ABOVE CENTER REAR VIEW MIRROR) SLIDING/ POP-UP ROOF DRIVE ASSEMBLY SR LOCK PROTECTION SENSOR UNIT SR SWITCH VIO WIRE WHT WIRE YEL WIRE
