Instrument cluster circuit for Mercedes-Benz S-class AMG W220 (1999-2002)

ABS MIL AUDIBLE TURN SIGNAL INDICATOR BLK WIRE BLK/GRN WIRE BLK/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (BENEATH LEFT SIDE OF DASH) DISTRONIC WARNING INDICATOR ECT GAUGE ELECTRONIC CLOCK ELECTRONIC SPEEDO- METER ENGINE DIAGNOSTICS INDICATOR ESP WARNING INDICATOR FUEL LEVEL/ RESERVE INDICATOR FUSE 20 FUSE 21 FUSE 22 GEAR INDICATOR GRN WIRE GRN/WHT WIRE HIGH BEAM INDICATOR HOT AT ALL TIMES HOT IN ACC, RUN OR START HOT IN RUN OR START INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION INSTRUMENT/SEARCHLAMP ILLUMINATION BRIGHTNESS CONTROL REGULATOR LEFT FUSE BOX (ON LEFT REAR CORNER OF ENGINE COMPARTMENT) LEFT TURN SIGNAL INDICATOR LOW BRAKE FLUID LEVEL/ PARKING BRAKE INDICATOR LOW WINDSHIELD WASHER FLUID LEVEL INDICATOR MULTIFUNCTION INDICATOR OUTSIDE TEMPERATURE INDICATOR PNK WIRE RED WIRE RED/YEL WIRE RESTRAINT SYSTEM CONTROL MODULE RIGHT TURN SIGNAL INDICATOR SRS INDICATOR TACHO- METER WARNING BUZZER WHT WIRE WHT/BLU WIRE YEL WIRE
