Power windows circuit for Mercedes-Benz R-class W251 facelift (2007-2010)

1 2 4 5 CAN-B H CAN-B L 30 31 17 18 CAN-B H CAN-B L 4 3 CAN-B H CAN-B L BLU/BLK WIRE BRN WIRE BRN/RED WIRE CLOSE VENT WINDOW SWITCH COMFORT ACC PUSHBUTTON CONTROL MODULE (IF EQUIPPED) ACC PUSHBUTTON COMPUTER DATA LINES SYSTEM CONTROL MODULE DRIVER POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP EIS (EZS) CONTROL UNIT FRONT PASSENGER POWER WINDOW SWITCH FUSE 26 FUSE 34 HOT AT ALL TIMES LEFT FRONT DOOR CONTROL MODULE (IN LEFT FRONT DOOR) LEFT FRONT POWER WINDOW MOTOR (CENTER OF LEFT FRONT DOOR) LEFT FRONT POWER WINDOW SWITCH LEFT REAR POWER WINDOW SWITCH LOAD COMPARTMENT FUSE, RELAY BOX (RIGHT SIDE OF CARGO AREA) NCA WIRE OPEN VENT WINDOW SWITCH ORG/ WIRE PNK WIRE REAR SIDE WINDOWS CHILD SAFETY LOCK SWITCH RED WIRE RIGHT FRONT DOOR CONTROL MODULE (IN RIGHT FRONT DOOR) RIGHT FRONT POWER WINDOW MOTOR (CENTER OF RIGHT FRONT DOOR) RIGHT FRONT POWER WINDOW SWITCH RIGHT REAR POWER WINDOW SWITCH WHT WIRE

16 26 CAN-B H CAN-B L BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE CAN-B H CAN-B L CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR CIRCUIT 31 RIGHT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR COMPUTER DATA LINES SYSTEM FRONT SAM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT) FUSE 88 GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT REAR FOOTWELL LEFT REAR POWER WINDOW MOTOR (CENTER OF LEFT REAR DOOR) LEFT REAR POWER WINDOW SWITCH LEFT VENT WINDOW MOTOR (IN LEFT "D" PILLAR) LEFT VENT WINDOW OBSTRUCTION SENSOR STRIP (IN LEFT VENT WINDOW FRAME) NCA WIRE PNK WIRE REAR SAM CONTROL MODULE (RIGHT REAR OF CARGO AREA) RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT REAR POWER WINDOW MOTOR (CENTER OF RIGHT REAR DOOR) RIGHT REAR POWER WINDOW SWITCH RIGHT VENT WINDOW MOTOR (IN RIGHT "D" PILLAR) RIGHT VENT WINDOW OBSTRUCTION SENSOR STRIP (IN RIGHT VENT WINDOW FRAME) VIO/BLK WIRE VIO/WHT WIRE VOLTAGE DISTRIBUTOR CONNECTOR WHT WIRE
