Ventilation & heated seat circuit for Mercedes-Benz R-class W251 facelift (2007-2010)

1 2 3 4 5 6 31 30 HL HR CAN B L CAN B H 1 2 3 4 5 6 7 8 9 10 31 31 SIG SIG 30 3 1 SIR SIL 31 31 PNK WIRE 36 35 CAN-B H CAN-B L BACKREST HEATED CUSHION BLU WIRE BLU/BLK WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CIRCUIT 31 LEFT FOOTWELL VOLTAGE DISTRIBUTOR CONNECTOR 1 CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR 3 CIRCUIT 31 RIGHT FOOTWELL VOLTAGE DISTRIBUTOR CONNECTOR COMPUTER DATA LINES SYSTEM FRONT SAM CONTROL UNIT (UNDER FRONT PASSENGER'S SEAT) FUSE 31 FUSE, RELAY BOX (RIGHT REAR OF CARGO AREA) FUSE 68 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT FRONT HS SWITCH LEFT FRONT SEAT BACKREST VENTILATION MOTOR GROUP (IN LEFT FRONT SEAT BACK) LEFT FRONT SEAT CUSHION VENTILATION MOTOR GROUP (IN LEFT FRONT SEAT CUSHION) LEFT FRONT SEAT HEATED CUSHION LEFT FRONT SEAT VENTILATION BLOWER REGULATOR LEFT FRONT SEAT VENTILATION SWITCH RIGHT FRONT HS SWITCH LEFT REAR FOOTWELL LHZ- NCA WIRE PNK WIRE RED WIRE RIGHT FRONT BACKREST HEATED CUSHION RIGHT FRONT SEAT BACKREST VENTILATION MOTOR GROUP (IN RIGHT FRONT SEAT BACK) RIGHT FRONT SEAT CUSHION VENTILATION MOTOR GROUP (IN RIGHT FRONT SEAT CUSHION) RIGHT FRONT SEAT HEATED CUSHION RIGHT FRONT SEAT VENTILATION BLOWER REGULATOR (IN RIGHT FRONT SEAT BACK) RIGHT FRONT SEAT VENTILATION SWITCH SEAT HEATED CUSHION STEERING COLUMN MODULE (IF EQUIPPED) (TOP OF STEERING COLUMN) UPPER CONTROL PANEL CONTROL MODULE VIO WIRE VIO/BLK WIRE
