Instrument illumination circuit for Mercedes-Benz R-class W251 facelift (2007-2010)

17 18 CAN B L CAN B H 30 31 LIN 35 36 CAN-B L CAN-B H BLK WIRE BLK/BLU WIRE BLU WIRE BRIGHT INSTRUMENT, SEARCH ILLUMINATION PUSH BUTTON BRIGHTNESS SENSOR BRN WIRE BRN/RED WIRE CIRCUIT 31 RIGHT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR COMPUTER DATA LINES SYSTEM CUP HOLDER 1 ILLUM CUP HOLDER 2 ILLUM CUP HOLDER ILLUMINATION CUP HOLDER ILLUMINATION (W/ INTERIOR PACKAGE) DARK INSTRUMENT, SEARCH ILLUMINATION PUSH BUTTON DISTRIBUTOR CONNECTOR EXTERIOR LAMP SWITCH FRONT ARMREST FOLDING COMPARTMENT ILLUMINATION (W/ INTERIOR PACKAGE) FRONT CENTER CONSOLE CUP HOLDER ILLUMINATION (W/ INTERIOR PACKAGE) FRONT CIGAR LIGHTER W/ ASHTRAY ILLUMINATION FRONT SAM CONTROL UNIT (UNDER RIGHT FRONT SEAT) FUSE (RIGHT REAR OF CARGO AREA) FUSE 60 GLOVE COMPARTMENT ILLUMINATION (W/ SWITCH) GRN/BLK WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HOT W/ CIRCUIT INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION LEFT AIR OUTLET ILLUMINATION LEFT CENTER AIR OUTLET ILLUMINATION LIN LOAD COMPARTMENT FUSE, RELAY BOX PNK/BLK WIRE REAR CENTER CONSOLE ILLUMINATION REAR CENTER CONSOLE ILLUMINATION 2 RED WIRE RED/BLU WIRE RIGHT AIR OUTLET ILLUMINATION RIGHT CENTER AIR OUTLET ILLUMINATION UPPER CONTROL PANEL MODULE WAKE-UP SIGNAL/CIRCUIT
