Mercedes-Benz R-class W251 facelift (2007–2010) wiring diagrams

Automatic a/c circuit, without thermotronic Automatic a/c circuit, with thermotronic

Anti-lock brakes circuit

Front sam control module circuit Rear sam control module circuit

Data link connector circuit High/low bus circuit

Cooling fan circuit

3.0l turbo diesel, cruise control circuit

3.5l, cruise control circuit

Heated mirrors circuit Rear defogger circuit

Electronic power steering circuit

Electronic suspension circuit

Wiring diagram engine performance 3.0l diesel

Wiring diagram engine performance 3.5l

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit Overhead console circuit

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Passenger"s memory seat circuit Steering column memory circuit

Comand actuation circuit Emergency call circuit Parktronic circuit Rear camera circuit Voice activation circuit

Power distribution circuit

Automatic door locks circuit Keyless go system circuit

Automatic day/night mirror circuit Power mirror circuit

Adjustable pedal circuit Heated steering wheel circuit Ventilation & heated seat circuit Weight sensing system circuit

Power top/sunroof circuit

Power windows circuit

Dvd player circuit Most data bus circuit Rear audio circuit Satellite radio circuit Sound amplifier circuit Voice activation circuit

Charging circuit Starting circuit

Emergency seat belt tensioners circuit Supplemental restraint circuit

Transmission circuit

Seat belt warning circuit Tire pressure monitoring circuit

Front wiper/washer circuit Headlamp washer circuit Rear wiper/washer circuit

AMPLIFIER FOR SOUND SYSTEM AUXILIARY BATTERY BATTERY COMPARTMENT BATTERY COMPARTMENT PREFUSE BOX (UNDER RIGHT HEATED REAR WINDOW, LEFT ANTENNA COIL 1, LEFT ANTENNA COIL 2 HEATER COIL HEATER COIL TEMP SENS LEFT ANTENNA COIL 1 LEFT ANTENNA COIL 2 RIGHT ANTENNA COIL SOUND AMPLIFIER MICROPHONE

AIR COMPRESSOR MOTOR BLOWER MOTOR DRIVER FRONT SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT FORE/AFT ADJUSTMENT MOTOR ELECTRIC SUCTION FAN ENGINE AND AC W/ INTEGRATED CONTROL ENGINE CIRCUIT ENGINE CONTROLS, INSTRUMENT CLUSTER SYSTEMS LEFT DYNAMIC CORNERING LAMP MOTOR LEFT HEADLAMP RANGE ADJUSTMENT MOTOR LEFT HIGH BEAM LEFT LOW BEAM MIRROR IN/OUT MOTOR MIRROR MIRROR HEATER FOLD IN MOTOR MIRROR UP/DOWN MOTOR OF ENGINE) RIGHT DYNAMIC CORNERING LAMP MOTOR RIGHT HEADLAMP RANGE ADJUSTMENT MOTOR RIGHT HIGH BEAM SOLENOID RIGHT MIRROR EXTERIOR FOLD IN MIRROR MOTOR TURN SIGNAL LAMP TAILGATE WIPER MOTOR

14 13 15 10 GND NF L NF R ANTENNA ANTENNA 30 CAN-B L MUTE CAN-B H 31 ANTENNA CTEL ANTENNA

BLOWER REGULATOR BRIGHT INSTRUMENT, SEARCH ILLUMINATION PUSH BUTTON DARK INSTRUMENT, SEARCH ILLUMINATION PUSH BUTTON LEFT FRONT SEAT VENTILATION BLOWER REGULATOR MB-INFO, TELEDIAGNOSIS BUTTON GROUP RWTS BUTTON TRIP ODOMETER RESET BUTTON

BACKUP CAMERA BACKUP CAMERA CIRCUIT SOUND SYSTEMS BACKUP CAMERA VOLTAGE SUPPLY MODULE

CARGO AREA SOCKET CIRCUIT 31 CONNECTOR CIRCUIT 31 LEFT FOOT WELL VOLTAGE DISTRIBUTOR CONNECTOR CIRCUIT 31 LEFT FOOTWELL VOLTAGE DISTRIBUTOR CONNECTOR 1 CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR 1 CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR 1, 3 CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR 2 CIRCUIT 31 LEFT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR 3 CIRCUIT 31 RIGHT FOOTWELL VOLTAGE DISTRIBUTOR CONNECTOR CIRCUIT 31 RIGHT REAR SEAT VOLTAGE DISTRIBUTION CONNECTOR CIRCUIT 31 RIGHT REAR SEAT VOLTAGE DISTRIBUTOR CONNECTOR DISTRIBUTOR CONNECTOR FROM SOCKET CIRCUIT RIGHT FOOTWELL VOLTAGE DISTRIBUTOR CONNECTOR ROW SOCKET SOCKET CIRCUIT VOLTAGE DISTRIBUTOR CONNECTOR

AAC PUSHBUTTON CONTROL MODULE CDI CONTROL MODULE CENTRAL GATEWAY CONTROL MODULE DATA LINK CONNECTOR COMAND OPERATING, DISPLAY, CONTROL MODULE COMFORT AAC PUSHBUTTON CONTROL MODULE CONTROL MODULE ELECTRIC SUCTION FAN ENGINE, A/C W/ INTEGRATED CONTROL ESP CONTROL MODULE ESP CONTROL MODULE FRONT SAM CONTROL MODULE FUEL PUMP CONTROL MODULE LEFT FRONT DYNAMIC SEAT CONTROL MODULE ME-SFI CONTROL MODULE OVERHEAD CONTROL PANEL CONTROL MODULE REAR SAM CONTROL MODULE RESTRAINT REAR SAM CONTROL SYSTEMS MODULE CONTROL MODULE RESTRAINT SYSTEMS CONTROL MODULE RIGHT FRONT DYNAMIC SEAT CONTROL MODULE UPPER CD CHANGER CONTROL PANEL CONTROL MODULE UPPER CONTROL PANEL CONTROL MODULE

AC RECIRCULATION UNIT DC/AC CONVERTER CONTROL UNIT FRONT SAM CONTROL UNIT GARAGE DOOR OPENER TRANSMITTER UNIT INTERIOR REARVIEW MIRROR UNIT LEFT FRONT HEADLAMP UNIT ME SFI CONTROL UNIT (TOP CENTER MULTIFUNCTION STEERING WHEEL ELECTRONICS UNIT (INSIDE STEERING REAR AUDIO CONTROL UNIT RIGHT FRONT HEADLAMP UNIT TRACTION SYSTEM HYDRAULIC UNIT

BATTERY COMPT PREFUSE BOX FUSE 84 COCKPIT FUSE BOX FROM FUSE 36 DIAGRAM FUSE 32 FUSE 7 FUSE 8 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 21 FUSE 23 FUSE 34 FUSE 26 FUSE 24 FUSE 22 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 29 FUSE 40 FUSE 31 FUSE 32 FUSE 33 FUSE 25 FUSE 39 FUSE 34 FUSE 35 FUSE 36 FUSE 37 FUSE 41 FUSE 42 FUSE 42 FUSE 41 FUSE 20 FUSE 43 FUSE 44 FUSE 46 FUSE 48 FUSE 49 FUSE 50 FUSE 51 FUSE 52 FUSE 53 FUSE 54 FUSE 56 FUSE 55 FUSE 55 FUSE 54 FUSE 57 FUSE 58 FUSE 59 FUSE 55 FUSE 60 FUSE 61 FUSE 62 FUSE 63 FUSE 66 FUSE 67 FUSE 67 FUSE 30 FUSE 68 FUSE 69 FUSE 70 FUSE 68 FUSE 78 FUSE 79 FUSE 79 FUSE 80 FUSE 78 FUSE 82 FUSE 81 FUSE 83 FUSE 84 FUSE 85 FUSE 86 FUSE 87 FUSE 88 FUSE 88 FUSE 89 FUSE 90 FUSE 90 FUSE 89 FUSE 88 FUSE 91 FUSE 100 FUSE 101 FUSE 101 FUSE 104 FUSE 105 FUSE 102 FUSE 103 FUSE 105 FUSE 107 FUSE 108 FUSE 109 FUSE 111 FUSE 111 FUSE 110 FUSE 112 FUSE 113 FUSE 113 W/ CUSTOMER OPTION FUSE 114 FUSE 115 FUSE 116 FUSE 116 FUSE 117 FUSE 118 FUSE 120 FUSE 121 FUSE 123 HOT AT ALL TIMES BATTERY COMPARTMENT PREFUSE BOX FUSE 88 LOAD COMPARTMENT FUSE BOX, LOAD COMPARTMENT FUSE, RESERVE FUSE RESERVE FUSE 124 RESERVE FUSE 125

RIGHT MIRROR OUTSIDE HEATER MIRROR AMBIENT LAMP STEERING WHEEL HEATER STEERING WHEEL HEATER/FANFARE HORNS ELECTRONICS

ABS MIL INDICATOR AIR BAG INDICATOR AIR BAG INDICATOR, WARNING LAMP AUDIBLE TURN SIGNAL INDICATOR AUTOMATIC CHILD SEAT RECOGNITION AIRBAG OFF INDICATOR LAMP BRAKE FLUID, PARKING BRAKE WARNING LAMP INDICATOR CHECK ENGINE MIL INDICATOR ESP WARNING LAMP INDICATOR FUEL RESERVE INDICATOR LAMP GARAGE DOOR OPENER INDICATOR LAMP HIGH BEAM INDICATOR HIGH BEAM INDICATOR LAMP LEFT TURN SIGNAL INDICATOR LEFT TURN SIGNAL INDICATOR LAMP LOW BEAM INDICATOR LAMP MALFUNCTION DISPLAY INDICATOR PARKING BRAKE INDICATOR SWITCH PREGLOW INDICATOR LAMP RIGHT TURN SIGNAL INDICATOR RIGHT TURN SIGNAL INDICATOR LAMP STEERING WHEEL HEATER FUNCTION INDICATOR LAMP

AMBIENT LAMP AUTOMATIC AMBIENT DIMMING LAMP MIRROR BRAKE FLUID, PARKING BRAKE WARNING LAMP CENTER HIGH MOUNTED STOP LAMP DOOR LOCKS SYSTEM INTERIOR, EXTERIOR LIGHTS SYSTEMS ENTRANCE, EXIT LAMP ESP WARNING LAMP IND EXTERIOR INTERIOR LIGHTS LIGHTS SYSTEM SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR DEFOGGER LIGHTS SYSTEM SYSTEM INTERIOR LIGHTS SYSTEM NAVIGATION SYSTEM INTERIOR LIGHTS SYSTEM, POWER WINDOWS SYSTEM LEFT BACKUP LAMP LEFT DOME LAMP LEFT FOG LAMP LEFT FRONT DOOR ENTRANCE, EXIT LAMP LEFT FRONT FOOTWELL LAMP LEFT FRONT SIDE MARKER LAMP LEFT INTERIOR LAMP LEFT LEFT EXTERIOR OUTSIDE MIRROR MIRROR TURN AMBIENT SIGNAL LAMP LAMP LEFT READING LAMP LEFT REAR END DOOR LICENSE PLATE LAMP LEFT REAR FOOTWELL LAMP LEFT STANDING, PARKING LAMP LEFT STOP LAMP, TAILLAMP, PARKING LAMP, SIDE MARKER LAMP LEFT TURN SIGNAL LAMP READING LAMP REAR DOME LAMP PTS WARNING DISPLAY REAR END DOOR AMBIENT LAMP REAR FOG LAMP RIGHT BACKUP LAMP RIGHT DOME LAMP 35 36 CAN-B L CAN-B H RIGHT FOG LAMP RIGHT FRONT DOOR ENTRANCE, EXIT LAMP RIGHT FRONT FOOTWELL LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT INTERIOR LAMP RIGHT READING LAMP RIGHT READING LAMP LEFT READING LAMP RIGHT REAR END DOOR LICENSE PLATE LAMP RIGHT REAR FOOTWELL LAMP RIGHT STANDING, PARKING LAMP RIGHT STOP LAMP, TAILLAMP, PARKING LAMP, SIDE MARKER LAMP RIGHT TRUNK LAMP RIGHT TURN SIGNAL LAMP SEAT BELT REMINDER LAMP SEATS SYSTEM INTERIOR LIGHTS SYSTEM SEATS SYSTEM TIRE PRESSURE MONITOR WARNING LAMP WARNING LAMP

GLOW TIME OUTPUT STAGE, AIR PUMP HIGH PRESSURE, RETURN PUMP REAR DOOR HYDRAULIC PUMP TRANSMISSION OIL COOLER CIRCULATION PUMP

AIR PUMP RELAY AIR SUSPENSION COMPRESSOR RELAY CIRCUIT 15 RELAY COOLANT CIRCULATION PUMP RELAY ENGINE CIRCUIT 87 RELAY ENGINE COMPARTMENT FUSE , RELAY BOX ENGINE COMPARTMENT FUSE, RELAY BOX (RIGHT SIDE OF ENGINE FANFARE HORN RELAY FRONT PASSENGER SEAT ADJUSTMENT COMFORT RELAY FUEL PUMP MODULE RELAY FUSE 61 RELAY HOT W/ CIRCUIT 15 RELAY ENERGIZED HOT W/ ENGINE CIRCUIT 87 RELAY ENERGIZED LOAD COMPARTMENT FUSE, RELAY BOX LOAD COMPARTMENT FUSE, RELAY BOX (RIGHT REAR LOAD COMPARTMENT FUSE, RELAY BOX (RIGHT REAR OF LOAD COMPT FUSE, RELAY BOX FUSE 24 LOAD COMPT FUSE, RELAY BOX FUSE 59 REAR WINDOW DEFROSTER RELAY REAR WIPER RELAY RELAY ENERGIZED SPARE 2 RELAY STARTER RELAY TRAILER CIRCUIT 30 RELAY WIPER LEVEL 1, 2 RELAY WIPER LEVEL 1/2 RELAY WIPER ON/OFF RELAY

BRIGHTNESS SENSOR DIAPHRAGM TRAVEL SENSOR DRIVER'S SIDE FRONTAL ACCELERATION SENSOR EVAPORATOR TEMPERATURE SENSOR FUEL PRESSURE SENSOR INTAKE AIR TEMPERATURE SENSOR LEFT CENTER OUTLET TEMPERATURE SENSOR LEFT FOOTWELL TEMPERATURE SENSOR LEFT FRONT WHEEL SPEED SENSOR LEFT FRONT WSS SENSOR LEFT HOT FILM MAF SENSOR LEFT REAR DOOR PRESSURE SENSOR LEFT REAR WHEEL SPEED SENSOR LEFT REAR WSS SENSOR LEFT SIDE AIRBAG SENSOR LEFT SIDE OUTLET TEMPERATURE SENSOR OIL TEMPERATURE SENSOR PASSENGER'S SIDE FRONTAL ACCELERATION SENSOR PRESSURE SENSOR PRESSURE SENSOR DOWNSTREAM OF AIR CLEANER REAR END DOOR OPENING ANGLE RECOGNITION SENSOR RIGHT CENTER OUTLET TEMPERATURE SENSOR RIGHT FOOTWELL TEMPERATURE SENSOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT FRONT WSS SENSOR RIGHT HOT FILM MAF SENSOR RIGHT REAR DOOR PRESSURE SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT REAR WSS SENSOR RIGHT SIDE AIRBAG SENSOR RIGHT SIDE OUTLET TEMPERATURE SENSOR STEERING ANGLE SENSOR

LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER SUBWOOFER LOUDSPEAKER

CLOSE VENT WINDOW SWITCH COMBINATION SWITCH CRUISE CONTROL SWITCH DOOR CONTACT ON, OFF SWITCH DOOR CONTACT ON/OFF SWITCH DRIVER POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH DRIVER SEAT W/ MEMORY ADJUSTMENT SWITCH GROUP DRIVER' SEAT ADJUSTMENT SWITCH EXTERIOR LAMP SWITCH EXTERIOR MIRROR FOLD IN/ FOLD OUT SWITCH FRONT PASSENGER POWER WINDOW SWITCH FRONT PASSENGER SEAT ADJUSTMENT SWITCH FRONT PASSENGER SEAT W/ MEMORY ADJUSTMENT SWITCH GROUP GEAR SELECTOR SWITCH DIRECT SELECT GLOVE COMPARTMENT ILLUMINATION SWITCH HAZARD WARNING SWITCH 4 3 5 6 CAN-B L CAN-B H 30 31 HAZARD WARNING SYSTEM SWITCH HIGH BEAM SWITCH LEFT FRONT DYNAMIC SWITCH LEFT FRONT HS SWITCH LEFT FRONT LUMBAR SUPPORT ADJUSTMENT SWITCH LEFT FRONT MULTICONTOUR BACKREST SWITCH GROUP LEFT FRONT POWER WINDOW SWITCH LEFT FRONT PULSE SWITCH LEFT FRONT SEAT CUSHION FORE/ AFT ADJUSTMENT SWITCH LEFT FRONT SEAT VENTILATION SWITCH LEFT FRONT SEAT VENTILATION SWITCH RIGHT FRONT HS SWITCH LEFT FRONT SIDE BOLSTERS ADJUSTMENT SWITCH LEFT FRONT VANITY ILLUMINATION SWITCH LEFT INTERIOR CL [ZV] SWITCH LEFT OUTSIDE MIRROR ADJUSTMENT SELECTION SWITCH LEFT READING LAMP SWITCH LEFT REAR POWER WINDOW SWITCH LEVEL ADJUSTMENT SWITCH OPEN VENT WINDOW SWITCH OUTSIDE MIRROR ADJUSTMENT ROCKER SWITCH PASSENGER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH PTS OFF SWITCH RAISE/LOWER, FORWARD/ BACKWARD SWITCH REAR DOME LAMP, SWITCH REAR SIDE WINDOWS CHILD SAFETY LOCK SWITCH RELEASE SWITCH RIGHT FRONT DYNAMIC SWITCH RIGHT FRONT HS SWITCH RIGHT FRONT LUMBAR SUPPORT ADJUSTMENT SWITCH RIGHT FRONT MULTICONTOUR BACKREST SWITCH GROUP RIGHT FRONT POWER WINDOW SWITCH RIGHT FRONT PULSE SWITCH RIGHT FRONT SEAT CUSHION FORE/ AFT ADJUSTMENT SWITCH RIGHT FRONT SEAT VENTILATION SWITCH RIGHT FRONT SIDE BOLSTERS ADJUSTMENT SWITCH RIGHT FRONT VANITY ILLUMINATION SWITCH RIGHT INTERIOR CL [ZV] SWITCH RIGHT OUTSIDE MIRROR ADJUSTMENT SELECTION SWITCH RIGHT READING LAMP SWITCH RIGHT REAR POWER WINDOW SWITCH ROOF SWITCH ROW INTERIOR LAMP SWITCH SIGNAL, SWITCH SOS PUSHBUTTON SWITCH STEERING COLUMN ADJUSTMENT, STEERING WHEEL HEATER SWITCH STEERING COLUMN ADJUSTMENT/STEERING WHEEL HEATER SWITCH STEERING WHEEL HEATER SWITCH TRANSMISSION MODE SWITCH WINDSHIELD WASHER SYSTEM SWITCH WIPE SWITCH

AIR PUMP SWITCHOVER VALVE AIRMATIC PRESSURE REDUCTION VALVE CENTRAL RESERVOIR CHARGE VALVE DRIVER NECK-PRO HEAD RESTRAINT SOLENOID FRONT AXLE INLET SOLENOID VALVE FRONT AXLE SWITCHOVER SOLENOID VALVE FRONT PASSENGER NECK-PRO HEAD RESTRAINT SOLENOID HEATING SYSTEM SHUTOFF VALVE LEFT FRONT SOLENOID VALVE 2 LEFT HIGH BEAM SOLENOID LEFT REAR SOLENOID VALVE 1 LEFT REAR SOLENOID VALVE 2 LEFT REAR VALVE REAR AXLE SWITCHOVER SOLENOID VALVE RIGHT FRONT SOLENOID VALVE 1 RIGHT LEFT REAR FRONT VALVE VALVE VALVE RIGHT REAR SOLENOID VALVE 1 SOLENOID VALVE SOLENOID VALVE REAR AXLE INLET VARIABLE INTAKE MANIFOLD SWITCHOVER VALVE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PNK 30 31 31 WIRE 1 2 3 4 5 6 7 8 9 10 11 12 PNK WIRE 1 2 3 4 5 6 7 8 9 10 49 HI LI PNK WIRE 1 3 2 PNK WIRE 2 3 4 1 PNK WIRE 2 4 11 1 10 17 3 12 9 8 PNK 30 31 DATA WIRE 31 31 PNK WIRE (OR RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/PNK WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/WHT WIRE PNK 1 2 3 WIRE PNK EC LED TDC LED IC LED ECS ICS ICS CRASH WIRE PNK MIC 1 MIC 3 WIRE PNK SK SS FA WIRE PNK SS BF WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/BRN WIRE PNK/GRN WIRE PNK/GRY WIRE PNK/RED WIRE PNK/WHT WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RWTL PNK WIRE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 MIC OUT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 CAN-C H CAN-C L 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 CAN-B L CAN-B H DATA 30 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 SIG DIAG SIG SIG SIG SIG SIG SIG 1 2 3 4 5 6 7 8 9 10 11 12 AUX L SHIELD 1 2 3 4 5 6 7 8 9 10 31 31 SIG SIG 30 1 2 3 4 5 6 7 8 30 31 CAN-B H CAN-B L 30 31 LIN 1 2 3 4 5 6 7 8 ANT GND 1 2 3 4 5 6 7 8 HR+ VR+ VL+ HL+ HR- VR- VL- HL- 1 2 3 4 5 6 31 30 HL HR CAN B L CAN B H 1 2 3 4 5 6 CA 1 2 3 4 5 6 CB 1 2 3 4 5 6 CAN C H CAN C L 1 2 3 4 5 6 CAN H CAN L 15 30 31 30 1 2 3 4 5 CAN-B H CAN-B L 31 30 30 1 2 3 4 5 CAN-C L CAN-C H ISM 30 31 1 2 3 4 31 30 CAN-B H CAN-B L 1 2 3 4 31 30 CAN-B L CAN-B H 1 2 3 4 31 30 WAKE UP 1 2 3 4 CAN B L CAN-B H SIG 1 2 3 4 LHZ FAF 31 DIAG 1 2 3 5 31 SIG 1 1 2 3 30 31 WAKE-UP 1 2 3 CAN-C H CAN-C L 1 2 3 LIN 31 30 1 2 4 5 CAN-B H CAN-B L 30 31 1 2 5 4 CAN-B L CAN-B H 31 30 1 2 CAN B L CAN B H 1 2 CAN-B H CAN-B L 1 2 CAN-C H CAN-C L 1 2 COMPUTER CAN-C H CAN-C L DATA LINES SYSTEM 1 2 GND NTC 1 2 MOST 1 MOST IN MOST OUT 1 2 MOST 12 MOST IN MOST OUT 1 2 MOST 18 MOST IN MOST OUT 1 2 MOST IN MOST OUT 1 2 MOST MOST IN MOST OUT 1 2 MOST OUT MOST IN 1 6 5 30 CAN-C L CAN-C H 1.ZYL 2 1 5 4 CAN-B L CAN-B H 31 30 2 1 CAN-B H CAN-B L 2 1 CAN-B L CAN-B H 2 1 CAN-C H CAN-C L 2 1 CAN-C L CAN-C H 2 1 COMPUTER CAN-C H CAN-C L DATA LINES SYSTEM 2 1 MOST 3 MOST OUT MOST IN 2 1 MOST OUT MOST IN 2.ZYL 3 1 2 5 6 GND OR IR- IR+ IR DATA 3 1 SIR SIL 3 2 1 31 CAN-D H CAN-D L 3 4 7 6 5 CAN-B H CAN-B L LIN 31 30 3 4 CAN B H CAN B L 3 4 CAN-D H CAN-D L 3 5 LD- LD+ 3 BREMSL 3.0L TURBO 3.5L 3.5L 3.0L 3.BREMSL 3.ZYL 4 1 2 5 30 CAN-B H CAN-B L 31 4 2 30 CAN-B L CAN-B H 4 2 CAN-B H CAN-B L 4 3 2 1 DIAG 31 FAF LHZ 4 3 2 1 KI.58 4 3 5 6 CAN-B H CAN-B L CAN-C H CAN-C L 4 3 CAN B L CAN B H 4 3 CAN-B H CAN-B L 4 12 13 1 30 CAN-C L CAN-C H 31 4.ZYL 5 3 CAN-B H CAN-B L 5 4 2 1 3 6 30 30 CAN-B L CAN-B H 31 31 5 4 6 14 15 16 17 18 19 20 9 8 10 LL L GND TA LL R LL L 5 6 3 13 CAN-B H CAN-B L 5 6 7 30 31 LIN 5 6 CAN-B L CAN-B H 5.0L, 5.5L 5.ZYL 6 3 2 1 31 31 CAN-B L CAN-B H 6 5 CAN-B H CAN-B L 6 5 CAN-C L CAN-C H 6 5 COMPUTER CAN-C L CAN-C H DATA LINES SYSTEM 6 7 CAN-D H CAN-D L 6.ZYL 7 5 4 3 RWLT 7 5 CAN-B H CAN-B L 7 8 CAN-C L CAN-C H 8 3 RF RE RF LI 8 7 6 GND GND 8 9 12 LL L LL R DATA 9 10 11 8 30 CAN-C H CAN-C L 31 10 9 2 1 CAN-B H CAN-B L 10 9 7 8 CAN-B H CAN-B L CAN-C L CAN-C H 10 9 8 7 6 5 4 3 2 1 CAN-B H CAN-B L CAN-C H CAN-C L 30 CAN-D H CAN-D L 10 11 BEL 31 10 11 CAN H CAN L 10 11 CAN-C H CAN-C L 11 4 2 DATA 31 30 11 9 11 9 CAN-B H CAN-B L 11 10 CAN-C L CAN-C H 11 15 CAN-C H CAN-C L 12 13 30 AUF 12 13 CAN-C L CAN-C H 13 12 6 CAN-C H CAN-C L 15 13 14 31 BBV HR BBV VR 14 4 CAN-C H CAN-C L 15 30 KPR 15 HRL 16 26 CAN-B H CAN-B L 17 18 1 25 16 CAN-C L CAN-C H 30 SK 31 17 18 CAN B L CAN B H 17 18 CAN-B H CAN-B L 17 27 16 26 CAN-B H CAN-B L CAN-B H CAN-B L 17 27 CAN-B H CAN-B L COMPUTER DATA LINES SYSTEM 18 17 13 12 CAN-B H CAN-B L CAN-C H CAN-C L 18 17 CAN-C H CAN-C L 25 9 CAN-B H CAN-B L 26 6 CAN-B L CAN-B H 26 16 CAN-B-L CAN-B-H 27 33 40 TG+R TG- TG+L 30 31 CAN B L CAN B H CAN C H CAN C L 30 31 LIN 30 CAN-B H CAN-B L 30 DVV 30 WAKE UP 31 30 CAN H CAN L 31 31 CAN L CAN H SIG CAK BF 31 CAN-B L CAN-B H 30 31 DATA 31 DATA IL R IL L 35 36 31 CAN-B L CAN-B H 35 36 CAN-B L CAN-B H 36 35 CAN-B H CAN-B L 39 52 TIG_L TIG_R 41 54 CAN-C H CAN-C L 45 41 54 61 CAN-C H CAN-C L 49 HI LI 49 HI RE 49 RE 49 LI 51 52 CAN-C H CAN-C L 54 41 7 24 15 12 40 11 24 41 67 72 CAN-CL CAN-CH 54 41 10 37 23 50 11 88 39 43 64 74 75 CAN-CL CAN-CH 58 LI 87 SIG #1 #2 #3 #4 #5 #6 (OR A/C COMPRESSOR (LEFT FRONT ABS IND. ACCEL SET/ AIR CONDITIONING SYSTEM AIRBAG SQUIB AKF+ ANT GND ANTI-THEFT SYSTEM AUTOMATIC DIMMING MIRROR AUX L + AUX R + BA MV 30 BACKREST HEATED CUSHION BAS BRAKE BOOSTER BBV HR BBV VR BOOSTER BLOWER ELECTRONIC BLOWER CONTROLLER BRAKE FLUID, PARKING BRAKE WARNING IND BRIGHT INSTRUMENT, SEARCH ILLUMINATION PUSHBUTTON BUS SIG CAK FA CAN B H CAN B L CAN B L CAN B H CAN C H CAN C H CAN C L CAN C L CAN C L CAN C H CAN H L CAN L CAN-B H 30 CAN-B H CAN-B H CAN-B H CAN-B L CAN-B H CAN-B L 31 30 CAN-B L 31 CAN-B H CAN-B L 31 CAN-B H 30 CAN-B L CAN-B L CAN-SH CAN-SL 31 CARGO AREA) CD CHANGER COCKPIT PREFUSE BOX COMPT) COMPUTER DATA CAN-B H 30 LINES SYSTEM COMPUTER DATA LINES SYSTEM CONTROL CONTACT CUP HOLDER 1 ILLUM CUP HOLDER 2 ILLUM CUP HOLDER ILLUMINATION DARK INSTRUMENT, SEARCH ILLUMINATION PUSHBUTTON DECEL/ SET DEFOGGER SYSTEM DFVR_S 54 DFHL_S DK_S+ DK_S_ DK_S- DKL DKP_M DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM WIPER/WASHER SYSTEM DRIVER BELT FORCE LIMITER DRIVER BUCKLE ETR SQUIB DRIVER SEAT EXTERNAL POWER FEED SEPARATION POINT DRIVER'S SIDE AIRBAG SQUIB DRS ODS DVD PLAYER EARLY PRODUCTION LATE PRODUCTION EKA-A ELECTRONIC CLOCK ELECTRONIC COMPASS (BEHIND INSTRUMENT ELECTRONIC SPEEDOMETER ELECTRONIC SUSPENSION SYSTEM ESP CONTROL INTELLIGENT SERVO MODULE MODULE FOR DIRECT SELECT ETR SQUIB EXCEPT 5.0L 36 35 CAN-B H CAN-B L COMPUTER DATA LINES SYSTEM FANFARE HORNS, AIRBAG CLOCK SPRING CONTACT FL GND TA RE TA LI FL GND TA RE TA LI LL R GND TA FRONT CIGAR LIGHTER W/ ASHTRAY ILLUMINATION FRONT PASSENGER AIRBAG SQUIB 1 FRONT PASSENGER AIRBAG SQUIB 2 FRONT PASSENGER BELT FORCE LIMITER FRONT PASSENGER BUCKLE ETR SQUIB FRONT PREFUSE FRONT SEAT) FUEL INJECTORS FUEL LEVEL, RESERVE GAUGE GKB BF GKB FA GLOW PLUGS GLOW TIME OUTPUT STAGE GND GND GND GND GND GND GND GND GND GND GND LIN GND LIN CAN-B H CAN-B L GND LL L TA GS BF GS HL HANDS-FREE SYSTEM MICROPHONE GROUP HEADLAMP FLASHER/ HEADLAMP FLASHER/ HIGH BEAM SW HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEATED MIRROR HEATED REAR WINDOW HFM-1 HFM-2 HIGH/LOW BUS CIRCUIT HL WE HOCH VOR CAN-B L HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START HOT IN RUN OR START HOT W/ CIRCUIT HR VR HL VL INJ L INJ L INJ L INJ L INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM INSTRUMENT CLUSTER SYSTEM WIPER/WASHER SYSTEM AIR CONDITIONING SYSTEM INSTRUMENT ILLUMINATION INSTRUMENT PANEL DRIVER SIDE PTS WARNING DISPLAY INTERFERENCE FILTER 1 KI 58 GND KRV ZWP KS_M KS_S KTS_S LATE PRODUCTION EARLY PRODUCTION LDF-1 LEFT AIR OUTLET ILLUMINATION LEFT CENTER AIR OUTLET ILLUMINATION LEFT ELECTRICALLY ADJUSTABLE, HEATED EXTERIOR MIRROR LEFT FOOTWELL) LEFT FRONT DOOR INSIDE HANDLE ILLUMINATION LEFT FRONT DOOR TWEETER LEFT FRONT IR RECEIVER LEFT FRONT KEYLESS GO DOOR HANDLE LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR LEFT FRONT SEAT HEATED CUSHION LEFT MULTIFUNCTION STEERING WHEEL PUSHBUTTON GROUP LEFT REAR AXLE LEFT REAR DISPLAY LEFT REAR DOOR TWEETER LEFT REAR FOOTWELL LEFT REAR KEYLESS GO DOOR HANDLE LEFT REAR SURROUND LOUDSPEAKER LEFT RIGHT TURN LEFT STEERING WHEEL GEAR SHIFTER LEFT SUN VISOR W/ ILLUMINATED MIRROR LEFT TAILLAMP LEFT WINDOW AIRBAG SQUIB LHP ZME+ LHP ZUE 1 ZUE 3 ZUE 2 LHZ- LL L LL R 31 DATA DATA LL R LL L LOW BEAM SW LSA CAN-H H LSP + CAN-D H CAN-D L MEMORY RECALL MIC 1 MIC GND LSP - MIC GND MIC OUT + MOST BUS MINIMUM EQUIPMENT MOST BUS MAXIMUM EQUIPMENT MOST DATA BUS CIRCUIT MOST IN MOST OUT MOT- MULTIFUNCTION DISPLAY NAVIGATION SYSTEM NF-L GND NF-R NWG_M NWSA 1 OF CARGO AREA) OSS + OVERHEAD CONTROL PANEL MODULE POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER WINDOWS SYSTEM RADIO INTERFERENCE SUPPRESSION CAPACITOR 1 RADIO INTERFERENCE SUPRRESION CAPACITOR 2 REAR CENTER CONSOLE ILLUMINATION REAR CENTER CONSOLE ILLUMINATION 2 REAR END DOOR RF LI RF RE RIGHT AIR OUTLET ILLUMINATION RIGHT CENTER AIR OUTLET ILLUMINATION RIGHT ELECTRICALLY ADJUSTABLE, HEATED EXTERIOR MIRROR RIGHT FRONT RIGHT FRONT BACKREST HEATED CUSHION RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION RIGHT FRONT DOOR TWEETER RIGHT FRONT KEYLESS GO DOOR HANDLE RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR RIGHT FRONT SEAT HEATED CUSHION RIGHT HIGH BEAM RIGHT MULTIFUNCTION STEERING WHEEL PUSHBUTTON GROUP RIGHT REAR DISPLAY RIGHT REAR DOOR RIGHT REAR DOOR TWEETER RIGHT REAR KEYLESS GO DOOR HANDLE RIGHT REAR SEAT VOLTAGE DISTRI- BUTOR CON- NECTOR RIGHT REAR SURROUND LOUDSPEAKER RIGHT SIDE AIRBAG SQUIB RIGHT STEERING WHEEL GEAR SHIFTER RIGHT SUN VISOR W/ ILLUMINATED MIRROR RIGHT TAILLAMP RIGHT WINDOW AIRBAG SQUIB SB BF + SB FA SB HL SB HR GS HR SEAT HEATED CUSHION SEATS SYSTEM SF FA SH SH- SHIELD AUX R SIG 15 SIG REL SIG SIG SIG SIG SIG SIG SIG SIG SIG SIG WAKE UP SIG WAKE UP SIG SIG SK SF BF SOUND SYSTEMS SPARK PLUGS STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM POWER WINDOWS SYSTEM WIPER/WASHER SYSTEM STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN MODULE SUPPLEMENTAL RESTRAINTS SYSTEM TG+R TIEF HOCH TIEF TIG L TG+L TK 31 30 TK MHK TRAILER CIRCUIT UPPER CONTROL PANEL MODULE VIDEO OUT VIDEO GND VL - VOR ZUR HOCH TIEF VOR ZUR HOCH TIEF W/ CUSTOMER OPTION W/ INTERIOR LIGHT PACKAGE W/ INTERIOR LIGHT PACKAGE W/O INTERIOR LIGHT PACKAGE W/ LEVEL CONTROL W/ REAR A/C W/O REAR A/C W/ REAR ENTERTAINMENT W/ REAR WINDOW DEFROSTER W/ SOUND SYSTEM W/O SOUND SYSTEM W/ XENON XENON W/KEYLESS GO W/O IR REMOTE CONTROL W/O CUSTOMER OPTION W/O KEYLESS GO W/ IR REMOTE CONTROL W/O REAR ENTERTAINMENT W/O SOUND SYSTEM W/O XENON XENON WAKE UP 31 WAKE UP SIGNAL WAKE-UP WAKE-UP SIGNAL/CIRCUIT WALKMAN SEPARATION POINT WARNING BUZZER WB R GS FA WHEEL) WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM DOOR LOCKS SYSTEM ZME_L ZUE 4 ZUE 6 ZUE 5 ZUR VOR HOCH ZV-T ZWP +
