High/low bus circuit for Mercedes-Benz Metris W447 (2015-2024)

BECKER MAP PILOT CONTROL UNIT BECKER MAP PILOT CONTROL UNIT MOUNT BLK WIRE BLK/WHT WIRE BRN WIRE BRN/RED WIRE CAMERA COVER (KAB) CONTROL UNIT CAN A H CAN A L CAN B H CAN B L FRONT PASSENGER FOOTWELL FUSE, RELAY MODULE FUSE 303 FUSE 304 HOT AT ALL TIMES LEFT FRONT DOOR CONTROL UNIT LEFT SLIDING DOOR (E-LSTL) CONTROL UNIT OVERHEAD CONTROL PANEL (OCP (DBE)) CONTROL UNIT PARAMETERIZABLE SPECIAL MODULE (PSM) CONTROL UNIT RED WIRE RED/BLK WIRE RIGHT FRONT DOOR CONTROL UNIT RIGHT SLIDING DOOR (E-LSTR) CONTROL UNIT TRAILER RECOGNITION (AAG) CONTROL UNIT

AIR CONDITIONING CONTROL, OPERATING UNIT (FRONT, REAR KLA) BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN A H CAN A L CAN B H CAN B L CAN B L COC CAN E H CAN E L CAN-G H CAN-G L DRIVER SEAT HEATER/ VENTILATION CONTROL UNIT ELECTRICAL POWER STEERING (ES) CONTROL UNIT ELECTRONIC IGNITION LOCK (EZS) CONTROL UNIT FRONT END CAN (CAN G) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR GRN WIRE GRN/WHT WIRE GRY/WHT WIRE INSTRUMENT CLUSTER (KI) CONTROL UNIT LEFT REAR BLIND SPOT ASSIST RADAR SENSOR MULTI-FUNCTION CAMERA (MFK) CONTROL UNIT PNK WIRE PNK/WHT WIRE RADIO (AUDIO) (IF EQUIPPED) REAR-END DOOR REVERSING CAMERA (RFK) CONTROL UNIT REVERSING CAMERA (RFK) CONTROL UNIT RIGHT REAR BLIND SPOT ASSIST RADAR SENSOR SIGNAL ACQUISITION, ACTUATION MODULE (SAM) CONTROL UNIT SUPPLEMENTAL RESTRAINT SYSTEM (SRS) CONTROL UNIT TIRE PRESSURE MONITOR (RDK) CONTROL UNIT UPPER CONTROL PANEL (UCP (OBF)) CONTROL UNIT W/ TWO LEAF REAR END DOOR W/O TWO LEAF REAR END DOOR

BLU WIRE BLU/WHT WIRE BRN WIRE CAN C H CAN C L CAN E H CAN E L COLLISION WARNING SYSTEM RADAR SENSOR DRIVETRAIN CAN (CAN C) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR ELECTRONIC STABILITY PROGRAM (ESP) CONTROL UNIT FUEL SYSTEM CONTROL UNIT (FSCU) FULLY INTEGRATED TRANSMISSION CONTROL (VGS) ELECTRIC CONTROLLER UNIT GRN WIRE GRN/WHT WIRE INTELLIGENT SERVO MODULE (ISM) CONTROL UNIT FOR DIRECT SELECT ME-SFI (ME) CONTROL UNIT PARKTRONIC CONTROL UNIT (PTS) STEERING COLUMN TUBE MODULE (MRM) CONTROL UNIT TRANSMISSION OIL AUXILIARY OIL PUMP CONTROL UNIT
