Mercedes-Benz Metris W447 (2015-2024) prefuse box/ starter electrical distributor rail Wiring diagrams
This page contains all the electrical diagrams for the component. prefuse box/ starter electrical distributor rail, in which he is found in the car Mercedes-Benz Metris W447 (2015-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
prefuse box/ starter electrical distributor rail wiring diagram (1 of 3)
ADDITIONAL BATTERY
ALTERNATOR
BACKUP BATT
BACKUP BATTERY
BATTERY CUTOFF RELAY
BATTERY SENSOR (ON BATTERY)
BLK WIRE
BLK/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
ECO START/STOP FUNCTION DIODE
ELECTRONIC IGNITION LOCK (EZS) CONTROL UNIT
EMERGENCY-P BATTERY
EMERGENCY-P BATTERY OR BACKUP BATTERY FUSE
FIREWALL FUSE, RELAY MODULE
FUSE 22
FUSE 25
GRN WIRE
GRN/WHT WIRE
INSTRUMENT CLUSTER (KI) CONTROL UNIT
ME-SFI (ME) CONTROL UNIT
NCA WIRE
NOT BATT -
ON-BOARD ELECTRICAL SYSTEM BACKUP BATTERY RELAY
ON-BOARD ELECTRICAL SYSTEM BATTERY
PREFUSE BOX
PREFUSE BOX/ ALTERNATOR ELECTRICAL DISTRIBUTOR RAIL
PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
PYROFUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/ORG WIRE
RIGHT END OF DASH)
SIGNAL ACQUISITION, ACTUATION MODULE (SAM) CONTROL UNIT
STARTER
SUPPLEMENTAL RESTRAINTS SYSTEM
TR SIG
VIO WIRE
W/ ECO START/ STOP FUNCTION
W/O ECO START/ STOP FUNCTION
W/O ECO START/STOP FUNCTION
WHT/BRN WIRE
Go to component -> Charging circuit -> PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
prefuse box/ starter electrical distributor rail wiring diagram (2 of 3)
ADDITIONAL BATTERY
ALTERNATOR
BATTERY CUTOFF RELAY
BATTERY SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
ECO START/STOP FUNCTION DIODE
ELECTRIC FAN
ELECTRICAL POWER STEERING (ES) CONTROL UNIT
GRN WIRE
N/A
ON-BOARD ELECTRICAL SYSTEM BATTERY
PREFUSE BOX/ ALTERNATOR ELECTRICAL DISTRIBUTOR RAIL
PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
REAR PASSENGER COMPARTMENT SOCKET RELAY
RED WIRE
RED/ORG WIRE
SIGNAL ACQUISITION, ACTUATION MODULE (SAM) CONTROL UNIT
STARTER
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) CONTROL UNIT
TO ENGINE COMPARTMENT FUSE, RELAY MODULE (DIAGRAM 2 OF 7)
TO FIREWALL FUSE, RELAY MODULE (DIAGRAM 4 OF 7)
TO FRONT PASSENGER FOOTWELL FUSE, RELAY MODULE (DIAGRAM 6 OF 7)
VIO WIRE
W/O ECO START/STOP FUNCTION
Go to component -> Power distribution circuit (1 of 7) -> PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
prefuse box/ starter electrical distributor rail wiring diagram (3 of 3)
BATTERY SENSOR (ON BATTERY)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN C H
CAN C L
CAN E H
CAN E L
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
ECO START/STOP FUNCTION BUTTON
ELECTRONIC IGNITION LOCK (EZS) CONTROL UNIT
ENGINE COMPARTMENT FUSE, RELAY MODULE
ENGINE COMPT)
FIREWALL FUSE, RELAY MODULE
FULLY INTEGRATED TRANSMISSION (VGS) ELECTRIC CONTROLLER UNIT
FUSE 84
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT 15 RELAY ENERGIZED
ME-SFI (ME) CONTROL UNIT
ON-BOARD ELECTRICAL SYSTEM BATTERY
PREFUSE BOX
PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
PYROFUSE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
STARTER
STARTER CIRCUIT 50 RELAY
STRH
STRL
SUPPLEMENTAL RESTRAINTS SYSTEM
SYSTEM
UPPER CONTROL PANEL (UCP(OBF)) CONTROL UNIT
VIO WIRE
W/ ACTIVE PARKING ASSIST, LANE KEEPING ASSIST
W/O ACTIVE PARKING ASSIST, LANE KEEPING ASSIST
Go to component -> Starting circuit -> PREFUSE BOX/ STARTER ELECTRICAL DISTRIBUTOR RAIL
