Tire pressure monitoring circuit for Mercedes-Benz Maybach GLS-class X167 (2019-2023)
Tire pressure monitoring circuit
BRN WIRE
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
FUSE 467
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL UNIT
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
REAR FUSE, RELAY MODULE
RED WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
TIRE PRESSURE MONITOR CONTROL UNIT
VIO WIRE
VIO/WHT WIRE
