Electronic suspension circuit for Mercedes-Benz Maybach GLS-class X167 (2019-2023)

ACTIVE ROLL STABILIZATION LATERAL ACCELERATION SENSOR ACTIVE SUSPENSION, DAMPING SYSTEM CONTROL UNIT BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN H H CAN H L COMPUTER DATA LINES SYSTEM FLEX-E BM FLEX-E BP FUSE 308 FUSE 336 FUSE 718 GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT BODY ACCELERATION SENSOR LEFT FRONT LEVEL SENSOR LEFT REAR LEVEL SENSOR NCA WIRE PASSENGER-SIDE A-PILLAR FUSE BOX PNK WIRE PNK/RED WIRE REAR BODY ACCELERATION SENSOR REAR END LOWERING SWITCH RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT AXLE DAMPING VALVE UNIT RIGHT FRONT BODY ACCELERATION SENSOR RIGHT FRONT LEVEL SENSOR RIGHT FRONT SOLENOID VALVE 1 RIGHT FRONT SOLENOID VALVE 2 RIGHT REAR AXLE DAMPING VALVE UNIT RIGHT REAR LEVEL SENSOR RIGHT REAR SOLENOID VALVE 1 RIGHT REAR SOLENOID VALVE 2 SIG STARTER BATTERY PREFUSE BOX VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE

BLK/RED WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM FRONT ACTIVE ROLL STABILIZATION ELECTRIC CONTROLLER UNIT FUSE 1 FUSE 2 FUSE 4 FUSE 6 HOT AT ALL TIMES LEFT FRONT AXLE DAMPING VALVE UNIT LEFT FRONT SOLENOID VALVE 1 LEFT FRONT SOLENOID VALVE 2 LEFT FRONT SUSPENSION STRUT ELECTROHYDRAULIC CONTROLLER UNIT LEFT REAR AXLE DAMPING VALVE UNIT LEFT REAR SOLENOID VALVE 1 LEFT REAR SOLENOID VALVE 2 LEFT REAR SUSPENSION STRUT ELECTROHYDRAULIC CONTROLLER UNIT LINES SYSTEM NCA WIRE REAR ACTIVE ROLL STABILIZATION ELECTRIC CONTROLLER UNIT RED WIRE RIGHT FRONT SUSPENSION STRUT ELECTROHYDRAULIC CONTROLLER UNIT RIGHT REAR SUSPENSION STRUT ELECTROHYDRAULIC CONTROLLER UNIT W/ ELECTROHYDRAULIC SUSPENSION W/O ELECTROHYDRAULIC SUSPENSION WHT WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE
