Charging circuit for Mercedes-Benz GLS-class X167 facelift (2023-2024)

3.0L TURBO HYBRID 4.0L TURBO HYBRID BATTERY DISCONNECT SWITCH RELAY BATTERY SENSOR BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN C H CAN C L CAN L H CAN L L COMPUTER DATA LINES SYSTEM DC/DC CONVERTER CONTROL UNIT FRONT SIGNAL ACQUISITION, ACTUATION MODULE CONTROL UNIT FUSE 315 FUSE 509 FUSE 702 GRN/WHT WIRE ME-SFI (ME) CONTROL UNIT NCA WIRE ON-BOARD ELECTRICAL SYSTEM BATTERY PASSENGER-SIDE A-PILLAR FUSE BOX POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/WHT WIRE SIG STARTER GENERATOR CONTROL UNIT VEHICLE INTERIOR PREFUSE BOX WHT WIRE YEL WIRE
