Armrest heated circuit for Mercedes-Benz GLS-class X167 facelift (2023-2024)
Armrest heated circuit (1 of 2)
A SIG
ARMREST HEATER CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT CENTER CONSOLE ARMREST HEATING ELEMENT
FUSE 449
GRN/GRY WIRE
HOT AT ALL TIMES
LEFT REAR DOOR ARMREST HEATING ELEMENT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR SEAT ARMREST HEATING ELEMENT
LIN
REAR FUSE, RELAY MODULE
REAR SEAT HEATERS CONTROL UNIT
REAR SIGNAL ACQUISITION, ACTUATION MODULE CONTROL UNIT
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SIG
Armrest heated circuit (2 of 2)
A SIG
BLK WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL UNIT
DRIVER'S DOOR
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 302
FUSE 406
FUSE 713
FUSE 714
HOT AT ALL TIMES
LEFT FRONT DOOR ARMREST HEATING ELEMENT
LEFT FRONT DOOR LINING HEATING ELEMENT
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT DOOR ARMREST HEATING ELEMENT
RIGHT FRONT DOOR LINING HEATING ELEMENT
RIGHT REAR DOOR
RIGHT REAR DOOR ARMREST HEATING ELEMENT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR SEAT ARMREST HEATING ELEMENT
SIG
STARTER BATTERY PREFUSE BOX
