Collision avoidance circuit for Mercedes-Benz GLS-class X167 facelift (2023-2024)
Collision avoidance circuit
ACTIVE BRAKE ASSIST CONTROLLER UNIT
BRN WIRE
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FLEX-E BM
FLEX-E BP
FUSE 207
FUSE 476
GRN/RED WIRE
HECKD
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL UNIT
PNK/RED WIRE
REAR FUSE, RELAY MODULE
REAR SIGNAL ACQUISITION, ACTUATION MODULE CONTROL UNIT
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO WIRE
VIO/WHT WIRE
