Mercedes-Benz GLS-class X166 (2015-2019) outside mirror fold-in/ fold-out switch Wiring diagram
This page shows the only wiring diagram for the component.outside mirror fold-in/ fold-out switch, which is found in the car Mercedes-Benz GLS-class X166 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside mirror fold-in/ fold-out switch (1 of 1)
AUTOMATIC DIMMING MIRROR
BATTERY COMPARTMENT PREFUSE BOX
BLK WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP
FUSE 253
FUSE 52
GRY/BLK WIRE
HORIZONTAL INCLINATION ADJUSTMENT ACTUATOR MOTOR
HOT AT ALL TIMES
INTERIOR PREFUSE BOX
LED
LED 31
LEFT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT POWER WINDOW SWITCH
LEFT OUTSIDE MIRROR
LEFT OUTSIDE MIRROR ADJUSTMENT SWITCH
LEFT OUTSIDE MIRROR AMBIENT LAMP
LEFT OUTSIDE MIRROR TURN SIGNAL LAMP
LEFT REAR POWER WINDOW SWITCH
MIRROR HEATER
NCA WIRE
OUTSIDE MIRROR ADJUSTMENT SWITCH
OUTSIDE MIRROR FOLD-IN/ FOLD-OUT ELECTRIC MOTOR
OUTSIDE MIRROR FOLD-IN/ FOLD-OUT SWITCH
RBA
REAR SIDE WINDOW CHILD SAFETY LOCK SWITCH
RED/WHT WIRE
RIGHT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT POWER WINDOW SWITCH
RIGHT OUTSIDE MIRROR
RIGHT OUTSIDE MIRROR ADJUSTMENT SWITCH
RIGHT OUTSIDE MIRROR AMBIENT LAMP
RIGHT OUTSIDE MIRROR TURN SIGNAL LAMP
RIGHT REAR POWER WINDOW SWITCH
SH(+) 61
SH(-) 31
SIG
VERTICAL INCLINATION ADJUSTMENT ACTUATOR MOTOR
