Mercedes-Benz GLK-class X204 facelift (2012-2015) Data link connector circuit

Data link connector circuit

Car Wiring Diagrams for GLK-class Mercedes-Benz X204 facelift (2012-2015): Data link connector circuit

BRN WIRE BRN/WHT WIRE CAN-D H CAN-D L DIAGNOSTIC CONNECTOR (DLC) FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE FUSE 73 GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES POWER DISTRIBUTION SYSTEM REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE RED/GRN WIRE
